ORIGINAL RESEARCH article

Front. Physiol., 25 November 2020
Sec. Autonomic Neuroscience
This article is part of the Research Topic Updates on the Neuropathology of Sudden Unexplained Perinatal Death and other Neurodevelopmental Disorders View all 15 articles

Immunohistochemical Expression of the Alpha Nicotinic Acetylcholine Receptor 7 in the Human Normal, Diabetic, and Preeclamptic Placenta and Products of Conception

\r\nAhmad Alwazzan&#x;Ahmad Alwazzan1†Riffat Mehboob,*&#x;Riffat Mehboob2,3*†Syed Amir GilaniSyed Amir Gilani2Amber HassanAmber Hassan2Shahida PerveenShahida Perveen4Imrana TanvirImrana Tanvir5Humaira WaseemHumaira Waseem2Kashifa EhsanKashifa Ehsan6Fridoon Jawad Ahmad,Fridoon Jawad Ahmad7,8Javed AkramJaved Akram7
  • 1Division of Gynecology Oncology, Faculty of Medicine, King Abdulaziz University, Jeddah, Saudi Arabia
  • 2Research Unit, Faculty of Allied Health Sciences, The University of Lahore, Lahore, Pakistan
  • 3SISSA, International School for Advanced Studies, Trieste, Italy
  • 4Department of Pathology, Continental Medical College Lahore, Lahore, Pakistan
  • 5Department of Pathology, King Abdulaziz University, Rabigh, Saudi Arabia
  • 6Shukat Khanum Memorial Hospital, Lahore, Pakistan
  • 7Physiology and Cell Biology Department, University of Health Sciences Lahore, Lahore, Pakistan
  • 8Institute of Regenerative Medicine, University of Health Sciences Lahore, Lahore, Pakistan

Preeclampsia (PE) and gestational diabetes (GD) are complications in advanced pregnancy while miscarriage for early pregnancy. However, the etiological factors are not well understood. Smoking has been associated with these complications as well as the sudden intrauterine deaths, sudden infant death, miscarriages, and still births. However, the immunolocalization of alpha 7 nicotine acetylcholine receptor (α7-nAChR) is not studied.

Materials and Methods: α7-nAChR subunit expression was evaluated in 10 paraffin-embedded placental tissues after delivery and 10 tissue samples of products of conception during first trimester by immunohistochemistry. Among the placental tissues, two samples were normal placental tissue, four from PE mother, and four from GD mother. The expression of α7-nAChR was compared between the two groups in general and within the subgroups of placenta as well. Protein expression was evaluated using the nuclear labeling index (%) of villi with positive cells stained, positive cells in the decidua, and intensity of staining in the outer villous trophoblast layer.

Results: The expression of α7-nAChR protein was high in all the cases of placenta and products of conception (POCs). α7-nAChR expression showed no notable differences among different cases of miscarriages irrespective of the mother’s age and gestational age at which the event occurred. However, there were some changes among the normal, PE, and GD placental groups in the linings of the blood vessels. Changes were restricted to the villi (as opposed to the decidua) lining cells, both cytotrophoblast and syncytiotrophoblast, and were specific to the α7 subunit. PE blood vessel lining was thicker and showed more expression of this receptor in endothelial cells and myofibroblasts in PE and GD groups. In POCs, the strong expression was observed in the decidua myocytes of maternal blood vessels and in syncytiotrophoblast and cytotrophoblast of chronic villi.

Conclusion: Nicotine acetyl choline receptors are found to be expressed highly in the placental tissues and in products of conception. They may be associated with the sudden perinatal deaths and miscarriages or complications of pregnancy.

Introduction

The prevalence of preeclampsia (PE) and gestational diabetes (GD) during pregnancy is 2–8% (Umesawa and Kobashi, 2017), respectively. The hazardous effects of exposure to tobacco smoking, whether active or passive, during pregnancy include placenta previa (Shobeiri and Jenabi, 2017), placental abruption (Ananth et al., 2016), ectopic pregnancy, early membrane rupture, low birth weight (Bar-Zeev and Solt, 2018), premature birth, sudden perinatal deaths, and stillbirths (Lavezzi et al., 2017; Anderson et al., 2019). We have highlighted these aspects in previous studies as well (Lavezzi et al., 2010, 2011, 2020; Mehboob, 2017; Mehboob et al., 2017; Muhammad et al., 2018).

Tobacco smoke contains many neurotoxic ingredients, but nicotine is the one with highest adverse effects on neurotransmission such as cholinergic system during the development of central nervous system in fetus (Klenowski and Tapper, 2018). Acetylcholine (ACh) is the main cholinergic neurotransmitter and has a basic functional role in the development of nervous system via its synaptic mechanisms of its nicotinic Ach receptors (nAChs) (Brown, 2019). There are nine nAChR subunits: α2, α3, α4, α5, α7, α9, β1, β2, and δ. Nicotine can mimic the effect of ACh and incorrectly signal the cholinergic system to activate when there is no requirement (Robbins, 2016).

Particularly, the α7 subunit affects the developing nervous system in a toxic way and damages the neuronal differentiation, angiogenesis, axon formation, and synaptic transmission (Cross et al., 2017; Lavezzi, 2018). This phenomenon highlights the vulnerability of α7-nAChRs as potential targets for other neurotoxicants, apart from nicotine, during the critical developmental phases of brain. A study was conducted to test this hypothesis, and it was observed that chlorpyrifos, an organophosphate pesticide used in agriculture, exhibits similar actions to those of nicotine in stimulating α7-nAChRs (del Pino et al., 2016). Previous studies have indicated that α2– 7-, 9, 10-, and β1-nAChR subunits are localized in the placenta (Ghazavi et al., 2013; Machaalani et al., 2014, 2018)) but with varying expressions depending on the structure and type of cell. However, a study that is detailed and in different populations has not been conducted yet.

Hence, the current study aimed to evaluate the immunohistochemical expression and localization of α7-nAChRs in three groups of placenta (normal, preeclamptic, and gestational diabetic) after delivery and retained products of conception (POCs) after miscarriage in the first trimester. The purpose is to assess the association with miscarriages and sudden perinatal deaths and explore the involvement of pesticides and smoking exposure in developing countries like Pakistan.

Materials and Methods

Tissue Collection

Ten placental tissue samples, comprising of two normal, four PE, and four GD samples, were obtained from the Obstetrics and Gynecology Department, after the ethical approval of The University of Lahore Teaching Hospital, Lahore, Pakistan. Placentas were collected within the first hour of delivery. Additionally, the retained POC tissue samples were collected from patients having miscarriages during the first trimester. Four small (2 × 2 cm) separate samples were obtained systematically from different areas of the POCs and placentas. Placental samples were obtained from the maternal side, code side alveoli, fetal side, and necrotic area and allowed to get fixed in 10% formalin for 24 h. Samples were embedded in paraffin and stored at room temperature for sectioning. Sections of 5 μm were cut using a microtome and mounted on 3-aminopropyltriethoxysilane (APES)-coated slides in preparation for staining. Tonsil tissue was used as a positive control for α7-nAChR receptor.

α7-nAChR Immunohistochemistry

Paraffin-embedded sections were deparaffinized with different grades of ethanol (100–70%), two washes in xylene for 5 min each and three washes in phosphate-buffered saline (PBS) (pH 7.4). Antigen retrieval was carried out by citrate buffer, heated for 60°C. Hydrogen peroxidase was used for blocking the endogenous peroxidase activity for 30 min at 4°C. Non-specificity in the tissue section was blocked by 10% normal rabbit serum and then incubated with the rabbit polyclonal, α7-nAChR primary antibody (Abcam, ab10096, 1:200 dilution) at 4°C overnight. Tissue sections were washed in PBS and incubated with goat antirabbit immunoglobulin G (IgG) secondary antibody (PK-6101, Vector Laboratories, CA, United States). Sections were further processed with the avidin–biotin immunoperoxidase technique (VEDH-4000, Vector Laboratories, CA, United States), counterstained with 3,3′-diaminobenzidine (DAB) and coverslipped.

Statistical Analysis

Data were analyzed by using SPSS 25.0. All the quantitative variables were presented in mean ± SD. Independent sample t test was applied to check the mean difference in both groups (placenta and POCs). P < 0.05 was considered as significant.

α 7-nAChR Expression Quantification

Immunoreactivity in the tissue sections was assessed in each randomly selected nucleus and cell as the number of cells exhibiting a dark brown stain, divided by the total cells, and shown as% [nAChR immunopositivity index (nAChR-I)] (Table 1) (Lavezzi et al., 2014).

TABLE 1
www.frontiersin.org

Table 1. Scoring scale for quantification of staining.

Quantitative Analysis for Immunohistochemistry

Images of placenta and POCs were captured using an Olympus BX40 microscope (Artisan Scientific, Champaign, IL, United States) at 10×, 20×, and 40× magnification. The number of cells with positive and negative stain in all the tissue sections was counted by using cell counter function manually.

Results

Patient Characteristics

There were 10 cases in the placenta and 10 cases in the POC groups. There were 2 cases in the placenta, 4 in the gestational diabetes, 4 in the pre/eclampsia, and 10 cases in the POC groups. The mean maternal age of patients in Group I was 33.20 ± 2.57 years and that in Group II was 33.20 ± 2.57 years (P < 0.05). The mean stain score in each group was 3.0 ± 0.0 (P > 0.05; P < 0.05) (Table 2).

TABLE 2
www.frontiersin.org

Table 2. Patients characteristics.

α7-nAChR Expression in Normal, PE, and GD Placenta and Product of Conception

Tonsillar tissue was strongly positive with + 3 intensity (Figures 1A–C). Immunohistochemical expression and localization of nAChR were evaluated and observed to be intense in all the cases of PE and GD as well as in the normal placenta (Figure 2) and POCs (Figure 3). α7-nAChR showed no significant differences among different cases of miscarriages irrespective of the mother’s age and gestational age at which the event occurred. The α7 receptor was widely distributed in the umbilical cord, fetal membranes, and placenta. There was intense staining in the decidual cells, trophoblastic cells of fetal membranes, and chorionic villi (Figure 2). The staining was primarily nuclear but also observed in cytoplasmic cells. Within the villi, the expression was highest, with no differentiation among the others (Figure 2). The specific staining pattern of α7-nAChR receptor was observed in the cell nucleus in the same decidua maternal villi in which cytoplasmic staining was well marked in syncytiotrophoblast and cytotrophoblast of chronic villi.

FIGURE 1
www.frontiersin.org

Figure 1. Control: tonsil (10×, 20×, 40×) strong positive stain in the squamous cells of lining epithelium (+3 intensity).

FIGURE 2
www.frontiersin.org

Figure 2. (A–D) Normal placenta (10×, 20×, 40×) revealed positive strong staining in chorionic villi lining cells both cytotrophoblast and syncytiotrophoblast. (E–H) Preeclampsia: Placenta (10×, 20×, 40×) shows increased thickness of media of the blood vessels walls with positive staining of endothelial cells and myofibroblast. (I–L) Gestational diabetes: Placenta revealed strong positivity of endothelial cell and myofibroblast (media is thickened) positive cell line (all + 3 intensity).

FIGURE 3
www.frontiersin.org

Figure 3. (A–E) Products of conception (POCs) (10×, 20×, 40×) showed strong staining in the decidua, endothelial, myocytes of maternal blood vessels, and in syncytiotrophoblast and cytotrophoblast of chronic villi (all + 3 intensity).

Discussion

The immunohistochemical expression of α7-nAChR subunit in the three groups of placentas (NP, PE, and GD) as well as in POCs showed villi changes specific to α7. The expression was high in the villi and decidua. To date, few studies have been found regarding the immunohistochemical expression of α7-nAChR in the placenta. This includes Lips et al. (2005) who reported the nAChR messenger RNA (mRNA) expression; Kwon et al. (2007) who reported α7 expression; and a recent study by Aishah et al. (2017, 2019) who reported the mRNA and protein expression of the α3 and β1 subunits. These studies showed that the nAChR subunits were expressed in the placenta, and their levels vary according to the cellular type. Herein, we report that the α7 subunit was more expressed in the villi and decidua and that they did not differ in the intensity of expression.

The study in 2018 by Machaalani et al. (2018) revealed the highest expression of α4 expression in placenta among the nine subunits studied. In our study, the highest α7 was in the normal placental cells of the villi lining cells both cytotrophoblast and syncytiotrophoblast. Increased thickness of media of the blood vessel walls with positive staining of endothelial cells and myofibroblast were seen in the PE and GD groups as compared to the control group. Small sample size is a limitation in our study.

Here, we have reported the protein localization and its expression in terms of intensity of α7-nAChR subunit in placental tissues and POCs in Pakistani population. The other subunits should also be explored in further studies. Additionally, different geographical locations within Pakistan, as well as in other countries, must also be investigated to see any possible differences. Pakistan is an agricultural country, and many banned pesticides are in use, e.g., dichlorodiphenyltrichloroethane (DDT), organochlorines, and organophophates, which have high nicotine content. Furthermore, cigarette smoking and huqqa smoking by men may put women and unborn child at risk due to passive smoking. This situation vary in different countries and may provide a possible link for diagnosis of at-risk individuals, awareness among society, and a direction for policy makers for banning the hazardous pesticides and smoking at public places.

Conclusion

Immunohistochemical expression and localization was almost similar in all placental groups and POCs. However, some exceptional prominent changes were in the villi in PE and GD groups. There was thickening of the lining of blood vessels in the placenta of these groups, which may be responsible for poor oxygen supply and complications for the fetus. More studies are required to further explore all nicotinic receptors in such cases to find a plausible association with sudden infant deaths, sudden intrauterine deaths, still births, and miscarriages.

Data Availability Statement

The original contributions presented in the study are included in the article/supplementary material, further inquiries can be directed to the corresponding author.

Ethics Statement

The studies involving human participants were reviewed and approved by the University of Lahore ethical review board. The patients/participants provided their written informed consent to participate in this study.

Author Contributions

AA contributed in the planning, write up and designing and facilitated financially and logistically to make this study happen. KE contributed in microscopy and preparing the figures. All the authors have contributed to this study.

Funding

The authors also thank The University of Lahore for providing some funding for the purchase of the antibodies used in this experimental work.

Conflict of Interest

The authors declare that the research was conducted in the absence of any commercial or financial relationships that could be construed as a potential conflict of interest.

Acknowledgments

We are highly grateful to the Late Vice Chancellor of The University of Lahore, Prof. Dr. M.H. Qazi, for his guidance and support in this project.

References

Aishah, A., Hinton, T., and Machaalani, R. (2017). Cellular protein and mRNA expression of β1 nicotinic acetylcholine receptor (nAChR) subunit in brain, skeletal muscle and placenta. Int. J. Dev. Neurosci. 58, 9–16. doi: 10.1016/j.ijdevneu.2017.01.011

PubMed Abstract | CrossRef Full Text | Google Scholar

Aishah, A., Hinton, T., Waters, K. A., and Machaalani, R. (2019). The α3 and α4 nicotinic acetylcholine receptor (nAChR) subunits in the brainstem medulla of sudden infant death syndrome (SIDS). Neurobiol. Dis. 125, 23–30. doi: 10.1016/j.nbd.2019.01.010

PubMed Abstract | CrossRef Full Text | Google Scholar

Ananth, C. V., Lavery, J. A., Vintzileos, A. M., Skupski, D. W., Varner, M., Saade, G., et al. (2016). Severe placental abruption: clinical definition and associations with maternal complications. Am. J. Obstet. Gynecol. 214, 272.e1–272.e9.

Google Scholar

Anderson, T. M., Ferres, J. M. L., Ren, S. Y., Moon, R. Y., Goldstein, R. D., Ramirez, J.-M., et al. (2019). Maternal smoking before and during pregnancy and the risk of sudden unexpected infant death. Pediatrics 143:e20183325. doi: 10.1542/peds.2018-3325

PubMed Abstract | CrossRef Full Text | Google Scholar

Bar-Zeev, Y., and Solt, I. (2018). Interventions for supporting women to stop smoking in pregnancy. Harefuah 157, 783–786.

Google Scholar

Brown, D. A. (2019). Acetylcholine and cholinergic receptors. Brain Neurosci. Adv. 3:2398212818820506. doi: 10.1177/2398212818820506

PubMed Abstract | CrossRef Full Text | Google Scholar

Cross, S. J., Linker, K. E., and Leslie, F. M. (2017). Sex-dependent effects of nicotine on the developing brain. J. Neurosci. Res. 95, 422–436.

Google Scholar

del Pino, J., Moyano, P., Anadon, M. J., García, J. M., Díaz, M. J., Gómez, G., et al. (2016). SN56 basal forebrain cholinergic neuronal loss after acute and long-term chlorpyrifos exposure through oxidative stress generation; P75NTR and α7-nAChRs alterations mediated partially by AChE variants disruption. Toxicology 353, 48–57.

Google Scholar

Ghazavi, E., David, R., Hinton, T., Makris, A., Hennessy, A., and Machaalani, R. (2013). PP007. Nicotinic acetylcholine receptor subunits in the pre-eclamptic and cigarette smoke exposed human placenta. Pregnancy Hypertension 3:70. doi: 10.1016/j.preghy.2013.04.035

PubMed Abstract | CrossRef Full Text | Google Scholar

Klenowski, P. M., and Tapper, A. R. (2018). “Molecular, neuronal, and behavioral effects of ethanol and nicotine interactions,” in The Neuropharmacology of Alcohol, eds K. A. Grant and D. M. Lovinger (Berlin: Springer), 187–212.

Google Scholar

Kwon, J.-Y., Kim, Y.-H., Kim, S.-H., Kang, M.-H., Maeng, Y.-S., Lee, K.-Y., et al. (2007). Difference in the expression of alpha 7 nicotinic receptors in the placenta in normal versus severe preeclampsia pregnancies. Eur. J. Obste. Gynecol. Reprod. Biol. 132, 35–39.

Google Scholar

Lavezzi, A. M. (2018). Toxic effect of cigarette smoke on brainstem nicotinic receptor expression: primary cause of sudden unexplained perinatal death. Toxics 6:63. doi: 10.3390/toxics6040063

PubMed Abstract | CrossRef Full Text | Google Scholar

Lavezzi, A. M., Corna, M. F., Alfonsi, G., and Matturri, L. (2014). Possible role of the α7 nicotinic receptors in mediating nicotine’s effect on developing lung–implications in unexplained human perinatal death. BMC Pulm. Med. 14:11. doi: 10.1186/1471-2466-14-11

PubMed Abstract | CrossRef Full Text | Google Scholar

Lavezzi, A. M., Corna, M. F., Mehboob, R., and Matturri, L. (2010). Neuropathology of the intermediolateral nucleus of the spinal cord in sudden unexplained perinatal and infant death. Int. J. Dev. Neurosci. 28, 133–138. doi: 10.1016/j.ijdevneu.2010.01.001

PubMed Abstract | CrossRef Full Text | Google Scholar

Lavezzi, A. M., Ferrero, S., Roncati, L., Piscioli, F., Matturri, L., and Pusiol, T. (2017). Nicotinic receptor abnormalities in the cerebellar cortex of sudden unexplained fetal and infant death victims-possible correlation with maternal smoking. ASN Neuro 9:1759091417720582. doi: 10.1177/1759091417720582

PubMed Abstract | CrossRef Full Text | Google Scholar

Lavezzi, A. M., Mehboob, R., Alfonsi, G., and Ferrero, S. (2020). Substantia nigra abnormalities provide new insight on the neural mechanisms underlying the sleep-arousal phase dysfunctions in sudden infant death syndrome. ASN Neuro 12:1759091420962695. doi: 10.1177/1759091420962695

PubMed Abstract | CrossRef Full Text | Google Scholar

Lavezzi, A. M., Mehboob, R., and Matturri, L. (2011). Developmental alterations of the spinal trigeminal nucleus disclosed by substance P immunohistochemistry in fetal and infant sudden unexplained deaths. Neuropathology 31, 405–413. doi: 10.1111/j.1440-1789.2010.01190.x

PubMed Abstract | CrossRef Full Text | Google Scholar

Lips, K., Brüggmann, D., Pfeil, U., Vollerthun, R., Grando, S., and Kummer, W. (2005). Nicotinic acetylcholine receptors in rat and human placenta. Placenta 26, 735–746. doi: 10.1016/j.placenta.2004.10.009

PubMed Abstract | CrossRef Full Text | Google Scholar

Machaalani, R., Ghazavi, E., Hinton, T., Makris, A., and Hennessy, A. (2018). Immunohistochemical expression of the nicotinic acetylcholine receptor (nAChR) subunits in the human placenta, and effects of cigarette smoking and preeclampsia. Placenta 71, 16–23. doi: 10.1016/j.placenta.2018.09.008

PubMed Abstract | CrossRef Full Text | Google Scholar

Machaalani, R., Ghazavi, E., Hinton, T., Waters, K. A., and Hennessy, A. (2014). Cigarette smoking during pregnancy regulates the expression of specific nicotinic acetylcholine receptor (nAChR) subunits in the human placenta. Toxicol. Appl. Pharmacol. 276, 204–212. doi: 10.1016/j.taap.2014.02.015

PubMed Abstract | CrossRef Full Text | Google Scholar

Mehboob, R. (2017). Substance P/Neurokinin 1 and trigeminal system: a possible link to the pathogenesis in sudden perinatal deaths. Front. Neurol. 8:82. doi: 10.3389/fneur.2017.00082

PubMed Abstract | CrossRef Full Text | Google Scholar

Mehboob, R., Kabir, M., Ahmed, N., and Ahmad, F. J. (2017). towards better understanding of the pathogenesis of neuronal respiratory network in sudden perinatal death. Front. Neurol. 8:320. doi: 10.3389/fneur.2017.00320

PubMed Abstract | CrossRef Full Text | Google Scholar

Muhammad, N., Sharif, M., Amin, J., Mehboob, R., Gilani, S. A., Bibi, N., et al. (2018). Neurochemical alterations in sudden unexplained perinatal Deaths-A review. Front. Pediatr. 6:6. doi: 10.3389/fped.2018.00006

PubMed Abstract | CrossRef Full Text | Google Scholar

Robbins, T. W. (2016). “Neurochemistry of cognition,” in Oxford Textbook of Cognitive Neurology and Dementia, eds M. Husain and J. M. Schott (Oxford: Oxford University Press), 91.

Google Scholar

Shobeiri, F., and Jenabi, E. (2017). Smoking and placenta previa: a meta-analysis. J. Mater. Fetal Neonatal Med. 30, 2985–2990. doi: 10.1080/14767058.2016.1271405

PubMed Abstract | CrossRef Full Text | Google Scholar

Umesawa, M., and Kobashi, G. (2017). Epidemiology of hypertensive disorders in pregnancy: prevalence, risk factors, predictors and prognosis. Hypertens. Res. 40, 213–220. doi: 10.1038/hr.2016.126

PubMed Abstract | CrossRef Full Text | Google Scholar

Keywords: placenta, products of conception, nicotine receptors, alpha 7 acetylcholine receptor, sudden perinatal deaths

Citation: Alwazzan A, Mehboob R, Gilani SA, Hassan A, Perveen S, Tanvir I, Waseem H, Ehsan K, Ahmad FJ and Akram J (2020) Immunohistochemical Expression of the Alpha Nicotinic Acetylcholine Receptor 7 in the Human Normal, Diabetic, and Preeclamptic Placenta and Products of Conception. Front. Physiol. 11:607239. doi: 10.3389/fphys.2020.607239

Received: 16 September 2020; Accepted: 13 October 2020;
Published: 25 November 2020.

Edited by:

Anna Maria Lavezzi, University of Milan, Italy

Reviewed by:

Kumar Sannagowdara, Advocate Aurora Health, United States
Muhammad Sulaiman Yousafzai, Yale University, United States
Bülent Eren, Kırklareli University, Turkey

Copyright © 2020 Alwazzan, Mehboob, Gilani, Hassan, Perveen, Tanvir, Waseem, Ehsan, Ahmad and Akram. This is an open-access article distributed under the terms of the Creative Commons Attribution License (CC BY). The use, distribution or reproduction in other forums is permitted, provided the original author(s) and the copyright owner(s) are credited and that the original publication in this journal is cited, in accordance with accepted academic practice. No use, distribution or reproduction is permitted which does not comply with these terms.

*Correspondence: Riffat Mehboob, mehboob.riffat@gmail.com

These authors share first authorship

Disclaimer: All claims expressed in this article are solely those of the authors and do not necessarily represent those of their affiliated organizations, or those of the publisher, the editors and the reviewers. Any product that may be evaluated in this article or claim that may be made by its manufacturer is not guaranteed or endorsed by the publisher.
