Retinal Vessel Metric Analysis of Type 1 Diabetes Mellitus in OCT Angiography
Provisionally accepted
- 1Department of Ophthalmology, First Affiliated Hospital, Nanjing Medical University, Nanjing, Liaoning Province, China
- 2School of Computer Science and Engineering, Nanjing University of Science and Technology, Nanjing, Jiangsu Province, China
- 3Department of Ophthalmology, Changzhou Third People's Hospital, Changzhou, Jiangsu Province, China
- 4Department of Ophthalmology, The Affiliated Taizhou People's Hospital of Nanjing Medical University, Taizhou, China
Select one of your emails
You have multiple emails registered with Frontiers:
Notify me on publication
Please enter your email address:
If you already have an account, please login
You don't have a Frontiers account ? You can register here
Purpose: To investigate retinal vascular characteristics in type 1 diabetes mellitus (T1DM) patients at different stages via optical coherence tomography angiography (OCTA).Design: A retrospective observational study.: 63 T1DM patients (110 eyes) who underwent OCTA (3*3mm) examination and 40 age-matched healthy individuals (79 eyes) were included. A deep learning model was used to segment the retinal arteries and veins on OCTA images, and the vascular metrics in the macular area, including fractal dimension (FD), vessel diameter index (VDI), vascular length fraction (VLF), vascular tortuosity, and vessel density (VD) in different zones (fovea, superior parafoveal, inferior parafoveal, nasal parafoveal, and temporal parafoveal) were calculated.In accordance to the diagnostic criteria for diabetic retinopathy (DR), T1DM patients were classified into groups. There were 12 individuals (19 eyes) in the NPDR group, all of whom exhibited non-proliferative DR, and 51 (91 eyes) in the NDR (non-DR) group. The NDR group was divided into 2 subgroups according to the duration of T1DM, with 28 people (49 eyes) having a duration of less than 5 years and 23 people (42 eyes) having a duration of 5 years or more. Built-in metrics of OCTA showed that the VD in each zone of NPDR group was significantly lower than that of control group and NDR group (all p < 0.05). In addition, the VD of the inferior parafoveal vein (P = 0.022) and superior parafoveal artery (P = 0.03) were significantly decreased in the NPDR group. Comparing the VD among NDR Vessel Metric Changes Of T1DM subgroups and control group, the VD of the superficial inferior parafovea of T1DM patients of early stage (less than 5 years) was significantly lower than that of normal people (p < 0.05), while the VD of the inferior parafoveal artery increased (P = 0.012).We employed a deep learning vessel segmentation model to analyze the changes in arterial and venous metrics in OCTA images of T1DM patients. Early damage of NPDR to large vessels occurs in the inferior parafoveal vein and the superior parafoveal artery. In patients without DR, the arterial VD of the inferior parafovea has a compensatory increase.
Keywords: Diabetic Retinopathy, type 1 diabetes mellitus, OCTA, Vessel density, deep learning Word Count：2886 Figure Count：4 Table Count：2 Vessel Metric Changes Of T1DM
