Embryo Selection at the Cleavage Stage Using Raman Spectroscopy of Day 3 culture medium and Machine Learning: A Preliminary Study

Fang Cao¹Wei Xiong²Xiaohui Lu¹Yanjun Luo³Rui Yan³Li Chen¹Yufeng Wang^1*Hanbi Wang^2*Xiuliang Dai^1*

• ¹Changzhou Maternal and Child Health Care Hospital, Changzhou, China
• ²Peking Union Medical College Hospital (CAMS), Beijing, Beijing Municipality, China
• ³Shanghai D-Band medical technology Co., Ltd, Shanghai, China

Background: Blastocyst transfer has been associated with shorter leukocyte telomere length in ART-conceived children, suggesting that extended embryo culture may accelerate aging in offspring. Selecting Day 3 embryos with high developmental potential for transfer could address this issue. The aim of this study is to investigate whether machine learning combined with Raman spectroscopy of spent Day 3 culture medium can serve as a potential method for predicting extended embryo culture outcomes, thereby enabling embryo selection at the cleavage stage. Methods This prospective study analyzed 172 Day 3 culture medium samples with known extended culture outcomes from 78 couples collected between February 2020 and February 2021. Samples were categorized into three groups based on extended culture outcomes: morphologically good blastocysts (group A), morphologically nongood blastocysts (group B), and clinically non-useful embryos (group C). For each sample, 30-40 Raman spectra were acquired. Machine learning analyses (both unsupervised and supervised) were performed for data visualization and clustering.Eighty percent of the samples from each group were used as training data, while the remaining 20% served as the test set. Twelve machine learning models, including both deep learning and traditional approaches, were independently trained and evaluated.Accuracy, sensitivity, and specificity were calculated for each model. Finally, the best four top-performing models were further combined using a stacking strategy for final prediction.The study included good-prognosis females (average age: 29.55 ± 2.94 years) with an adequate number of Day 3 embryos (median: 9 [7,11]). Supervised machine learning of labeled Raman spectra revealed distinct clusters for each group. The bestperforming models were multilayer perceptron, artificial neural network, gated recurrent unit, and linear discriminant analysis. Using the stacking strategy, two samples were misclassified, and 33 were correctly predicted. Sensitivity for A, B, and C predictions was 0.92, 1.00, and 0.94, respectively. Specificity for A, B, and C predictions was 1.00, 0.93, and 1.00, respectively. The overall accuracy, sensitivity, and specificity were 0.94, 0.93, and 0.97, respectively.Our preliminary study suggests that machine learning combined with Raman spectra of spent Day 3 culture medium represents a promising non-invasive approach for embryo selection at the cleavage stage
