CX3CR1 Fate-Mapping In Vivo Distinguishes Cochlear Resident and Recruited Macrophages After Acoustic Trauma

Sree Varshini Murali¹Andrew Stothert²Elyssa Pereyra³Lyumila Batalkina²Tejbeer Kaur^1*

• ¹Rutgers, The State University of New Jersey - Busch Campus, Piscataway, United States
• ²Creighton University Department of Biomedical Sciences, Omaha, Nebraska, United States
• ³Creighton University Department of Biology, Omaha, Nebraska, United States

Cochlear injury activates the resident macrophages (RM) and recruits the blood-circulating monocytes and monocyte-derived macrophages (Mo/Mo-M), but their specific functions in the injured cochlea are unknown. It is well established that the chemokine fractalkine receptor (CX3CR1), expressed by cochlear macrophages, influences the density of those macrophages and promotes synaptic repair and spiral ganglion neuron survival in the injured cochlea. As CX3CR1 is expressed on both RM and Mo/Mo-M, it remains unclear if CX3CR1-expressing RM and Mo/Mo-M are distinct and differentially promote SGN survival after cochlear injury. Here, we demonstrate the use of fate mapping via a tamoxifen-inducible CX3CR1 mouse model (CX3CR1YFP−CreERT2/wildtype:R26RFP) wherein CX3CR1-expressing RM and Mo/Mo-M are endogenously labeled with different fluorescent reporters to define the heterogeneity in cochlear macrophages regarding their origin, turnover, spatiotemporal distribution, morphology, and fate following a loud acoustic trauma. After 60 days of tamoxifen injections at 4 weeks of age, long-lived cochlear RM were YFP+ RFP+ with 98.0 ± 1.7% recombinant efficiency, and short-lived blood-circulating CX3CR1 lineage (Mo/Mo-M) were YFP+ RFP-with 2.5 ± 1.1% recombinant efficiency. Following an acoustic trauma of 112 dB SPL at 8-16 kHz octave band for 2 hours, morphologically similar RM and Mo/Mo-M were observed in the spiral ganglion, lamina, ligament, and around the sensory epithelium. Quantification of RM and Mo/Mo-M in the spiral lamina and ganglion revealed distinct spatial and temporal distribution patterns. Furthermore, recruited Mo/Mo-M expressed classical monocyte markers such as Ly6C and CCR2. Both RM and Mo/Mo-M were positive for proliferation marker, Ki67, and negative for apoptotic marker, cleaved caspase-3, suggesting that the overall increase in macrophage numbers in the noise-injured cochlea is a contribution of both the proliferation of RM and recruitment of Mo/Mo-M. Probing for blood-clotting protein, fibrinogen, showed its presence in the cochlea after acoustic trauma, suggesting vascular damage that positively and strongly correlated with the time course of recruitment of blood-circulating Mo/Mo-M in the noise-injured cochlea. These data imply that macrophages in the noise-injured cochlea are heterogeneous regarding their ontogeny, distribution, and fate. They offer a robust tool to study the precise roles of resident and recruited macrophages in healthy and pathological ears.
