A pilot study assessing the clinical utility of deep learning-reconstructed 3D-Echo-Planar-Imaging-based Quantitative Susceptibility Mapping in Multiple Sclerosis
Provisionally accepted
Dimitrios G. Gkotsoulias1,2,3*
Matthias Weigel1,2,3,4
Alessandro Cagol1,2,3,5
Nina de Oliveira Soares Siebenborn1
Josef Pfeuffer6
Cristina Granziera1,2,3- 1Translational Imaging in Neurology (ThINk) Basel, Department of Medicine and Biomedical Engineering, University Hospital Basel and University of Basel, Basel, Switzerland
- 2Department of Neurology, University Hospital of Basel, Basel, Switzerland
- 3Research Center for Clinical Neuroimmunology and Neuroscience Basel (RC2NB), University Hospital and University of Basel, Basel, Switzerland
- 4Division of Radiological Physics, Department of Radiology and Nuclear Medicine, University Hospital of Basel, Basel, Switzerland
- 5Department of Health Sciences, University of Genova, 16132, Genova, Italy
- 6Application Development, Siemens Healthineers AG, Erlangen, Germany
Select one of your emails
You have multiple emails registered with Frontiers:
Notify me on publication
Please enter your email address:
If you already have an account, please login
You don't have a Frontiers account ? You can register here
Background:Quantitative Susceptibility Mapping(QSM) has emerged as a promising paraclinical tool in Multiple Sclerosis (MS). This retrospective pilot study aims to evaluate whether a recently proposed deep learning-assisted, k-space-operating reconstruction, denoising and super-resolution technique(DLR) applied on 3D-Echo-Planar-Imaging(3DEPI) protocols, has the potential to improve the quality and clinical utility of QSM in Multiple Sclerosis, at 3T. Secondarily, we assess whether applying DLR versus a Conventional Reconstruction(CR) can improve the quality of QSM based on noise-susceptible, fast 3DEPI protocols.Methods:3T MRI 3DEPI-data were acquired on 7 MS patients and offline-reconstructed using CR and DLR. A sample size of 433 lesions was identified, based on FLAIR segmentation. Two experts, independently and method-blinded, rated lesion-wise the CR- and DLR-3DEPI-derived QSM, assessing the confidence in identifying paramagnetic rim lesions(PRLs), central vein sign(CVS), QSM hyper/isointense lesions and image quality. Gradient-Recalled-Echo(GRE), 2- and 1-average 3DEPI (Acquisition time:7:02/3:44/1:56min, respectively) from a healthy individual were offline-reconstructed using CR and DLR. Derived QSM maps were compared visually and quantitatively. Results:DLR-3DEPI-based QSM was rated significantly higher for the confidence in identification of the MS-specific biomarkers(hyper/isointense lesions:P<0.001, CVS: P=0.01) and overall image quality(P<0.001), compared to CR-3DEPI-based. Inter-method agreement was high for both raters(Cohen’s κ=0.98/0.92), suggesting that DLR improves the quality without changing the rater’s perception of the individual QSM-related clinical findings. Additionally, QSM derived from fast DLR-3DEPI with a 4-fold acquisition-time reduction compared to GRE, exhibited excellent visual and quantitative consistency with GRE-based QSM.Conclusion:Our results constitute a first demonstration of the enhanced quality and clinical utility of the DLR-3DEPI-based QSM in MS.
Keywords: Quantitative susceptibility mapping, GRE: Gradient Recalled Echo, 3DEPI: 3-dimensionalsegmented-Echo Planar Imaging, MS: Multiple Sclerosis, χ: Susceptibility, CVS: central vein sign, PRL: paramagnetic rim lesion, AI: artificial intelligence
Received: 12 Dec 2024; Accepted: 12 Jun 2025.
