Front. Cell Dev. Biol., 01 December 2021
Sec. Molecular and Cellular Pathology
Volume 9 - 2021 |

Novel BMP4 Truncations Resulted in Opposite Ocular Anomalies: Pathologic Myopia Rather Than Microphthalmia

Yi Jiang1 Jiamin Ouyang1 Xueqing Li1 Yingwei Wang1 Lin Zhou1,2 Shiqiang Li1 Xiaoyun Jia1 Xueshan Xiao1 Wenmin Sun1 Panfeng Wang1 Qingjiong Zhang1*
  • 1State Key Laboratory of Ophthalmology, Zhongshan Ophthalmic Center, Sun Yat-sen University, Guangzhou, China
  • 2Department of Ophthalmology, West China Hospital, Sichuan University, Chengdu, China

BMP4 variants have been reported to be associated with syndromic microphthalmia (MCOPS6, OMIM 607932). This study aims to describe BMP4 truncation mutations contributing to a novel phenotype in eight patients from four Chinese families. In this study, BMP4 variants were collected from a large dataset from in-house exome sequencing. Candidate variants were filtered by multiple in silico tools as well as comparison with data from multiple databases. Potential pathogenic variants were further confirmed by Sanger sequencing and cosegregation analysis. Four novel truncation variants in BMP4 were detected in four out of 7,314 unrelated probands with different eye conditions. These four mutations in the four families solely cosegregated in all eight patients with a specific form of pathologic myopia, characterized by significantly extended axial length, posterior staphyloma, macula patchy, chorioretinal atrophy, myopic optic neuropathy or glaucoma, vitreous opacity, and unique peripheral snow-grain retinopathy. The extreme rarity of the truncations in BMP4 (classified as intolerant in the gnomAD database, pLI = 0.96), the exclusive presence of these variants in the four families with pathologic myopia, variants fully co-segregated with the same specific phenotypes in eight patients from the four families, and the association of the pathogenicity of truncations with syndromic microphthalmia in previous studies, all support a novel association of BMP4 truncations with a specific form of pathologic myopia. The data presented in this study demonstrated that heterozygous BMP4 truncations contributed to a novel phenotype: pathologic myopia rather than microphthalmia. Mutations in the same gene resulting in both high myopia and microphthalmia have been observed for a few other genes like FZD5 and PAX6, suggesting bidirectional roles of these genes in early ocular development. Further studies are expected to elucidate the molecular mechanism of the bidirectional regulation.


Pathologic myopia is characterized by posterior staphyloma, fundus degenerative changes, and abnormal corrected visual acuity. Pathologic myopia usually belongs to a subgroup of high myopia, which is defined as an axial length of 26 mm or more (Ohno-Matsui et al., 2016; Sankaridurg et al., 2021; Spaide et al., 2021). The complications associated with pathologic myopia are among the first to third common causes of legal blindness worldwide (Wong et al., 2014; Sankaridurg et al., 2021). Genetic defects play a major role in the development of pathologic myopia or high myopia, and among these defects, at least 28 loci or genes have been reported to contribute to non-syndromic forms, while variants in a number of genes are known to cause syndromic forms. However, the genetic defects for most cases of high myopia or pathologic myopia are still unknown, and the identification of additional implicating genes may enrich our understanding of the pathogenesis and facilitate the prevention and management of these conditions (Zhang, 2021).

Comparative exome sequencing has been used to detect genetic factors contributing to retinitis pigmentosa and glaucoma in our previous studies (Sun et al., 2019; Yi et al., 2020). Using similar strategy, four truncation variants in BMP4 (OMIM 112262) were detected in four unrelated families with pathologic myopia. These variants were confirmed by Sanger sequencing and cosegregated with pathologic myopia in eight patients from four families but in none of the unaffected individuals or any in-house controls, suggesting that BMP4 may be an important factor for pathologic myopia. BMP4 plays a vital regulatory role in embryonic development (Hogan, 1996) and truncations in this gene are extremely rare and intolerant [gnomAD, probability of being loss-of-function intolerant (pLI) = 0.96; Exp. 14.2 with obs. 1]. Previously, truncations in BMP4 were reported to cause microphthalmia, anophthalmia, and coloboma (MAC) (Reis et al., 2011) and anterior segment dysgenesis (ASGD) (Takenouchi et al., 2013), phenotypes that in contrast to those of pathologic myopia. The identification of a novel and bidirectional ocular abnormality associated with BMP4 truncations may provide new clues for elucidation of the developmental regulation of ocular size and shape.

Materials and Methods

Patient Recruitment and Data Collection

The probands with different eye disorders and their related family members were enrolled through the Pediatric and Genetic Clinic, Zhongshan Ophthalmic Center. Clinical data and peripheral blood samples were collected from these individuals. Prior to collection, all the participants or their guardians voluntarily signed informed content according to the tenets of the Declaration of Helsinki. This study was approved by the Institutional Review Board of Zhongshan Ophthalmic Center. Genomic DNA was extracted from the leukocytes within peripheral venous blood samples by following a previously reported method (Wang et al., 2010).

Each participating individual received a routine ophthalmologic examination. Additional specific ocular examinations were performed when required, including anterior segment photography, fundus photography, optic coherence tomography (OCT), electroretinogram (ERG), and scanning laser opthalmoscopy (SLO).

Variant Detection and Evaluation

Whole-exome sequencing (Li et al., 2015) or target-exome sequencing (Wang et al., 2019) was performed on the genomic DNA from the 7,314 probands including 928 with early onset myopia, and 6,386 with other ocular conditions. After the detection of variants in BMP4 from the exome sequencing data, the variants were filtered by multiple bioinformatic analytic steps. First, variants with low sequencing quality with a coverage of less than 5 were excluded. Second, synonymous and non-coding variants without effects on splicing site alterations, which were predicted by the Berkeley Drosophila Genome Project,1 were excluded. Third, through the evaluation of the minor allelic frequencies (MAFs) of variants based on the gnomAD database,2 variants with an MAF ≥ 0.01 were excluded. The remaining variants were evaluated by five in silico tools, including SIFT,3 Polyphen-2,4 PROVEAN,5 CADD,6 and REVEL.7 Finally, the variants were classified as potential pathogenic variants (PPVs) after comparison with the distribution of variants in our cohort and the gnomAD database.

The variants were further confirmed by Sanger sequencing. The online design program Primer3.08 was used for primer design and the primer sequences are listed in Supplementary Table 1. Sanger sequencing validation including amplification, sequencing and target sequences analysis was performed following a previously described method (Chen et al., 2013). Then, the cosegregation analysis was conducted based on Sanger sequencing on genomic DNA from family relatives in these families.

Statistical Analysis

IBM SPSS software version 26.0 (Amonk, NY: IBM Corp.) was applied to all statistical analyses in this study. The comparison of the frequency of truncation variants between in-house data related to early onset myopia and data in the gnomAD database was analyzed using the chi-square test or Fisher’s exact test. An in-house data comparison between the frequency of these truncation variants in patients with early onset myopia and the frequency of these truncation variants in patients with other eye conditions was also performed using the chi-square test or Fisher’s exact test. A P-value less than 0.05 was considered as statistically significant.

Immunohistochemical Staining

To examine the BMP4 protein expression in the retinal tissue, immunohistochemical staining was performed on the human eyes of the donor who died of meningioma. The donor eyes were obtained from the Eye Bank of Guangdong Province. All the procedure was conducted following the Declaration of Helsinki and the written informed content was obtained from the donor before the study. The human eyes were fixed in the 4% paraformaldehyde and then embedded in paraffin. The paraffin-embedded eyes were cut into 4-μm-thick sections. Antigen retrieval was performed on the sections using high temperature (98°C) for 30 min and the sections were blocked with 5% normal goat serum. The primary antibodies, a mouse anti-BMP4 antibody (1:25; sc-12721; Santa Cruz) and a rabbit anti-PKC α antibody (1:500; sc-208; Santa Cruz), were used to incubate the sections. The secondary antibodies were Alexa Fluor 568-conjugated donkey anti-mouse IgG antibody (1:500; ab175472; Abcam) and Alexa Fluor 488-conjugated donkey anti-rabbit IgG antibodies (1:500; ab150073; Abcam) and DAPI (1:3000; 28718-90-3; Sigma-Aldrich) was used for the nuclear labeling. The images of stained sections were taken using the confocal microscope (Zeiss LSM 980, Carl Zeiss Microscopy GmbH, Jena, Germany).


Mutation Analysis

Totally, four novel truncation variants in BMP4 were identified in four out of 7,314 unrelated probands with different eye conditions, including c.43delC:p.(Gln15Lysfs4), c.97A > T:p.(Lys33), c.419delT:p.(Phe140Serfs13), and c.766C > T:p.(Arg256) (Figure 1). These four truncations were novel and potential candidates of disease-causing variants since this type of variants were extremely rare and intolerant based on gnomAD database (pLI = 0.96) (Figure 2B). In the current study, interestingly, all the four probands with these BMP4 truncations had early onset pathologic myopia, accounting for 4 of 928 probands with early onset high myopia, but in none of the 6,386 probands with other eye conditions (P = 2.58 × 10–4, Fisher’s exact test) (Figures 2A,C). Similarly, the frequency of BMP4 truncations in probands with early onset high myopia is significantly higher compared with the frequency in gnomAD (P = 1.23 × 10–7, Fisher’s exact test) (Figures 2A–C). The four truncations in our cohort were confirmed by Sanger sequencing and completely cosegregated with pathologic myopia in all eight patients from the four families (Table 1 and Figure 1): the c.97A > T:p.(Lys33) was a de novo variant presented in Family F3; another nonsense variant [c.766C > T:p.(Arg256)] and two frameshift variants [c.43delC:p.(Gln15Lysfs4); c.419delT:p.(Phe140Serfs13)] were segregated with pathologic myopia in the remaining three families. Here, four novel BMP4 truncation variants exclusively segregated with pathologic myopia in eight patients from four unrelated families suggests a novel bidirectional role of BMP4 in the normal and abnormal development of the eye, since most BMP4 variants were associated with microphthalmia-related disorders based on Human Gene Mutation Database (HGMD) database from previously studies (Bakrania et al., 2008; Hayashi et al., 2008; Reis et al., 2011; Lumaka et al., 2012; Huang X. et al., 2015; Blackburn et al., 2019; Nixon et al., 2019; Thanikachalam et al., 2020; Figure 2D).


Figure 1. The pedigrees and sequencing chromatograms of the four families in this cohort with potential pathogenic truncations. The filled pattern represents affected individuals. The square pattern indicates males, while the circle pattern indicates female. M represents the mutated allele and + represents the normal allele. The family number is shown above the pedigree and the amino acid effect of the mutation is shown below the pedigree.


Figure 2. The distribution and frequency of BMP4 variants in this cohort, the gnomAD database and the HGMD database. MAC, microphthalmia, anophthalmia, coloboma; ASGD, anterior segment dysplasia. (A) Diagram of the frequency and location of the detected BMP4 variants in mRNA sequences from our cohort (accession number NM_001202.6). The truncation variants are shown above and the missense variants are shown below. Compared with allele counts of missense variants in this cohort, the truncation variants are extremely rare. (B) Schematic showing the distribution and frequency of BMP4 variants in the gnomAD database. Truncation variants are rare in the general population (pLI = 0.96). (C) The distribution and frequency of potential pathogenic BMP4 truncation variants in our in-house data. The filled square pattern represents the phenotype related to BMP4 variants. The corresponding phenotype is shown above locations of the related variants. The potential pathogenic truncation variants in BMP4 are enriched in patients with pathologic myopia. (D) The distribution and frequency of BMP4 variants in previous studies. The truncation variants are shown above and the missense variants and large deletions are shown below. The blue rectangle patterns represent large deletions in BMP4. The position of references are indicated on the left of the pattern and the position of corresponding phenotypes is indicated on the right of the pattern. Based on the HGMD database, most reported disease-causing variants are associated with MAC and/or ASGD.


Table 1. Clinical information of the patients with BMP4 truncation variants in this study.

Clinical Characteristics

The clinical features of eight patients with novel BMP4 truncation variants were summarized in Table 1. Extra-ocular features were only observed in one of the eight patients, i.e., proband F4-II:3, who had tooth malformation, broad nasal bridge, and hyperextensible joints. Of the eight patients, the four probands were identified to have high myopia due to poor vision before school age. Subsequent systemic ocular examination on the probands and family members revealed pathologic myopia in eight patients from the four families. The best-corrected visual acuity (BCVA) among eight patients ranged from counting fingers (CF) to 1.00 (Snellen equivalent) and the mean BCVA was 0.45. The average axial length of eight patients was 30.62 mm (range, 25.32–37.88 mm). Additionally, the axial length of all patients but one family member (F2-I:2) was more than 26.00 mm. The axial length of F2-I:2 was 25.56 mm in the right eye and 25.32 mm in the left eye, her fundus changes showed a trend toward pathologic myopia. The fundus images of these patients demonstrated typical fundus changes for pathologic myopia, including tessellated fundus, posterior staphyloma, macula atrophy, patchy or diffuse chorioretinal atrophy, and peripheral chorioretinal degeneration (Figure 3). Interestingly, unique fundus changes were clearly observed in peripheral retinas of three patients from two families (F1-II;1, F1-II:2, and F2-II:1), i.e., numerous small white spots in the peripheral retina displayed a “snow grain” appearance (Figure 4). This characteristic phenotype has not been described previously in pathologic myopia so that it may be considered as a unique sign of pathologic myopia related to BMP4 truncation variants. The fundus autofluorescence and ERG test result were available from both eyes from the proband F1-II:2, demonstrating moderate reduction of rod and cone responses on ERG examination and relatively preserved autofluorescence with non-specific minor changes in the posterior and mid-peripheral retina (Supplementary Figure 1). Additionally, difference in severity of pathologic myopia between the two eyes was observed in all patients (Figures 3, 4), but such difference was relatively mild as compared with pathologic myopia due to mutations in genes responsible for Stickler syndrome or FEVR (unpublished data). The OCT scans of the four probands illustrated optic nerve fiber layer thinning and choroid atrophy (Supplementary Figures 2A–D). The white vitreous strands resembling gossamer anomalies were observed in anterior vitreous cavity in patients from two families (F1, F2) (Supplementary Figure 2E).


Figure 3. The fundus images of the probands in four families. (A,B,D) Typical pathologic myopia fundus changes in the right eyes of three patients from Family F1. All patients carried the same heterozygous truncation variant c.766C > T (p. Arg256*). Fundus photography of Patients F1-II:1 and F1-II:2 shows the ultra-widefield fundus imaging above and traditional fundus imaging of the posterior pole below. (C) The fundus images from the right eye of Patient F2-II:1 show diffuse chorioretinal atrophy and white spots in the peripheral retina. (E) Scanning laser ophthalmoscopy imaging of Patient F3-II:1 appears diffuse chorioretinal atrophy surrounding the optic disc region, patchy atrophy and posterior staphyloma. (F) Posterior staphyloma and diffuse chorioretinal atrophy around the optic disk are observed in the fundus photo of Patient F4-II:3.


Figure 4. The characteristic snow-grain like retinopathy in peripheral fundus of patients with BMP4 truncation variants. (A,C,E) Representative ultra-widefield fundus imaging of the left eyes from three patients: F1-II:1, F1-II:2, and F2-II:1. (B,D,F) The corresponding magnified image demonstrates that white dots in peripheral retina of the three patients closely resemble snow grains.


Previously, mutations in BMP4 were known to cause microphthalmia-related disorders (Bakrania et al., 2008; Reis et al., 2011). On the contrary, in the current study, four novel truncation variants in BMP4 were identified as PPVs in eight patients with pathologic myopia from four families. Our novel findings were supported by the following lines of evidences: (1) As described above, the truncation variants in BMP4 were extremely rare and intolerant in general population (gnomAD database, pLI = 0.96). Although the few BMP4 truncation variants have been reported are related to ocular phenotypes based on HGMD database, the loss of function variant has been identified as a disease-causative mutation related to ocular or systemic disorders. (2) As previously mentioned, the four BMP4 truncation variants considered PPVs, were highly enriched in 928 patients with early onset high myopia in this cohort. In contrast, none of potential pathogenic BMP4 truncation variants were identified in 6,386 patients with other eye conditions. Essentially, the clinical evidence supports that these four truncation variants contribute to phenotype—pathologic myopia. This point reflects that truncation variants in BMP4 are highly related to pathologic myopia. (3) None of these four BMP4 truncation variants were present in databases. These variants segregated with pathologic myopia in all families in this cohort. (4) In the same pedigree, all individuals with same BMP4 truncation variant exhibited a similar ocular phenotype. For example, in the family F1, the fundus images of mother and three children with same variant showed typical pathologic myopia fundus changes based on the Meta-Analysis for Pathologic Myopia (META-PM) classification (Ohno-Matsui et al., 2015). The same snow-grain degeneration in the peripheral retina was observed in the proband’s sister (F1-II:1) and the proband (F1-II:2). (5) In our study, the BMP4 protein expression mainly located in the inner nuclear layer and inner plexiform layer of adult human retina (Supplementary Figure 3), indicating that BMP4 might play pivotal role in visual and retinal development. (6) Previous genome-wide association studies on myopia identified that one of new genetic associations in European population was near the location of BMP4 (Kiefer et al., 2013). Based on the above evidences, the BMP4 truncation variants are suggested to cause pathologic myopia.

Interestingly, the novel phenotype related to BMP4 truncations observed in our cohort is opposite to previously reported phenotypes. In previous studies, variants in BMP4 have been mainly reported to be associated with microphthalmia, anophthalmia, coloboma (MAC) (Bakrania et al., 2008; Reis et al., 2011) and anterior segment dysgenesis (ASGD) (Takenouchi et al., 2013) in human. As a member of the BMP family and transforming growth factor-β (TGF-β) superfamily, BMP4 is known to play the critical role in the embryonic development (Hogan, 1996). In the eye, the BMP4 gene has been reported to be engaged in normal ocular morphogenesis involving lens induction (Huang J. et al., 2015), ciliary body formation (Rausch et al., 2018), and retinal development (Murali et al., 2005; Maruyama et al., 2006; Thompson et al., 2019). Previous studies and our current data indicate that BMP4 may play a bidirectional role in developmental regulation of ocular shape and size. Recently, genome-wide association studies based on a large population of individuals of European and Asian ancestry showed that the same set of variants shared contributions to the genetic risk of high myopia, low myopia and hyperopia (Tideman et al., 2021) in multifactorial manner. In fact, contrary phenotype due to a BMP4 truncation mutation was reported in one family, where the proband had unilateral anophthalmia, small cornea, and iris and chorioretinal coloboma, while his three family members with the same mutation had high myopia (Bakrania et al., 2008). Except for BMP4, opposite ocular phenotypes have been associated with mutations in other genes, such as FZD5, in which individuals with the same truncation variant or different eyes of the same individual exhibited either microphthalmia/uveal coloboma or high myopia (Jiang et al., 2021). Similar situation has been observed for PAX6, a gene known to cause aniridia when mutated, in which several single nucleotide polymorphisms are significantly associated with myopia (Hammond et al., 2004). Besides, similar situation also occurs in extraocular system, for example, variants in M4CR related to a gain of function tended to result in a lower risk of obesity while M4CR variants related to a loss of function contributed to a higher risk of obesity (Lotta et al., 2019). These evidences raise the hypothesis that some genes, such as BMP4, may be involved in bidirectional rather than unidirectional control of early ocular development. The mechanism of bidirectional regulation remains unknown and requires further studies.

In our current study, comparative exome sequencing, mutation-specific phenotypic clustering, cosegregation in multiple families, rarity and intolerant of truncations in general population, all provides strong evidence to support that truncation variants in BMP4 contribute to a novel phenotype of pathologic myopia. The snow-grain degeneration in the peripheral retina may be a characteristic sign specific for BMP4-related pathologic myopia. Further studies are expected to confirm our findings and to elucidate the underlying molecular mechanism of bidirectional regulation of eye development.

Data Availability Statement

The datasets presented in this study can be found from the following link: The accession number is HRA001597.

Ethics Statement

The studies involving human participants were reviewed and approved by Institute Review Board of the Zhongshan Ophthalmic Center. Written informed consent to participate in this study was provided by the participants’ legal guardian/next of kin.

Author Contributions

XX, SL, QZ, XJ, and LZ contributed to the patient recruitment and diagnosis. XX, QZ, XJ, YJ, JO, XL, YW, and LZ collected the clinical records. XX, SL, PW, and QZ performed the whole-exome analysis and targeted-exome sequencing. QZ contributed to the conception and design of this study and revised thoroughly the manuscript. WS, XX, PW, SL, QZ, and YJ performed the statistical analysis. YJ confirmed the variants by Sanger sequencing and family segregation analysis and wrote the first draft of the manuscript. All authors reviewed the manuscript and approved for submission.


This work was supported by the grants from National Natural Science Foundation of China (81770965) and the Fundamental Research Funds of the State Key Laboratory of Ophthalmology.

Conflict of Interest

The authors declare that the research was conducted in the absence of any commercial or financial relationships that could be construed as a potential conflict of interest.

Publisher’s Note

All claims expressed in this article are solely those of the authors and do not necessarily represent those of their affiliated organizations, or those of the publisher, the editors and the reviewers. Any product that may be evaluated in this article, or claim that may be made by its manufacturer, is not guaranteed or endorsed by the publisher.


We are grateful to all the probands and their family members who participated in this study.

Supplementary Material

The Supplementary Material for this article can be found online at:


  1. ^
  2. ^
  3. ^
  4. ^
  5. ^
  6. ^
  7. ^
  8. ^


Bakrania, P., Efthymiou, M., Klein, J. C., Salt, A., Bunyan, D. J., Wyatt, A., et al. (2008). Mutations in BMP4 cause eye, brain, and digit developmental anomalies: overlap between the BMP4 and hedgehog signaling pathways. Am. J. Hum. Genet. 82, 304–319. doi: 10.1016/j.ajhg.2007.09.023

PubMed Abstract | CrossRef Full Text | Google Scholar

Blackburn, P. R., Zepeda-Mendoza, C. J., Kruisselbrink, T. M., Schimmenti, L. A., García-Miñaur, S., Palomares, M., et al. (2019). Variable expressivity of syndromic BMP4-related eye, brain, and digital anomalies: a review of the literature and description of three new cases. Eur. J. Hum. Genet. 27, 1379–1388. doi: 10.1038/s41431-019-0423-424

CrossRef Full Text | Google Scholar

Chen, Y., Zhang, Q., Shen, T., Xiao, X., Li, S., Guan, L., et al. (2013). Comprehensive mutation analysis by whole-exome sequencing in 41 Chinese families with Leber congenital amaurosis. Invest. Ophthalmol. Vis. Sci. 54, 4351–4357. doi: 10.1167/iovs.13-11606

PubMed Abstract | CrossRef Full Text | Google Scholar

Hammond, C. J., Andrew, T., Mak, Y. T., and Spector, T. D. (2004). A susceptibility locus for myopia in the normal population is linked to the PAX6 gene region on chromosome 11: a genomewide scan of dizygotic twins. Am. J. Hum. Genet. 75, 294–304. doi: 10.1086/423148

PubMed Abstract | CrossRef Full Text | Google Scholar

Hayashi, S., Okamoto, N., Makita, Y., Hata, A., Imoto, I., and Inazawa, J. (2008). Heterozygous deletion at 14q22.1-q22.3 including the BMP4 gene in a patient with psychomotor retardation, congenital corneal opacity and feet polysyndactyly. Am. J. Med. Genet. A 146a, 2905–2910. doi: 10.1002/ajmg.a.32519

PubMed Abstract | CrossRef Full Text | Google Scholar

Hogan, B. L. (1996). Bone morphogenetic proteins in development. Curr. Opin. Genet. Dev. 6, 432–438. doi: 10.1016/s0959-437x(96)80064-80065

CrossRef Full Text | Google Scholar

Huang, J., Liu, Y., Oltean, A., and Beebe, D. C. (2015). Bmp4 from the optic vesicle specifies murine retina formation. Dev. Biol. 402, 119–126. doi: 10.1016/j.ydbio.2015.03.006

PubMed Abstract | CrossRef Full Text | Google Scholar

Huang, X., Xiao, X., Jia, X., Li, S., Li, M., Guo, X., et al. (2015). Mutation analysis of the genes associated with anterior segment dysgenesis, microcornea and microphthalmia in 257 patients with glaucoma. Int. J. Mol. Med. 36, 1111–1117. doi: 10.3892/ijmm.2015.2325

PubMed Abstract | CrossRef Full Text | Google Scholar

Jiang, Y., Ouyang, J., Li, S., Xiao, X., Sun, W., and Zhang, Q. (2021). Confirming and expanding the phenotypes of FZD5 variants: coloboma, inferior chorioretinal hypoplasia, and high myopia. Mol. Vis. 27, 50–60.

Google Scholar

Kiefer, A. K., Tung, J. Y., Do, C. B., Hinds, D. A., Mountain, J. L., Francke, U., et al. (2013). Genome-wide analysis points to roles for extracellular matrix remodeling, the visual cycle, and neuronal development in myopia. PLoS Genet. 9:e1003299. doi: 10.1371/journal.pgen.1003299

PubMed Abstract | CrossRef Full Text | Google Scholar

Li, J., Jiang, D., Xiao, X., Li, S., Jia, X., Sun, W., et al. (2015). Evaluation of 12 myopia-associated genes in Chinese patients with high myopia. Invest. Ophthalmol. Vis. Sci. 56, 722–729. doi: 10.1167/iovs.14-14880

PubMed Abstract | CrossRef Full Text | Google Scholar

Lotta, L. A., Mokrosiński, J., Mendes, de Oliveira, E., Li, C., Sharp, S. J., et al. (2019). Human gain-of-function MC4R variants show signaling bias and protect against obesity. Cell 177, 597–607.e9. doi: 10.1016/j.cell.2019.03.044

PubMed Abstract | CrossRef Full Text | Google Scholar

Lumaka, A., Van Hole, C., Casteels, I., Ortibus, E., De Wolf, V., Vermeesch, J. R., et al. (2012). Variability in expression of a familial 2.79 Mb microdeletion in chromosome 14q22.1-22.2. Am. J. Med. Genet. A 158a, 1381–1387. doi: 10.1002/ajmg.a.35353

PubMed Abstract | CrossRef Full Text | Google Scholar

Maruyama, Y., Mikawa, S., Hotta, Y., and Sato, K. (2006). BMP4 expression in the developing rat retina. Brain Res. 1122, 116–121. doi: 10.1016/j.brainres.2006.08.130

PubMed Abstract | CrossRef Full Text | Google Scholar

Murali, D., Yoshikawa, S., Corrigan, R. R., Plas, D. J., Crair, M. C., Oliver, G., et al. (2005). Distinct developmental programs require different levels of Bmp signaling during mouse retinal development. Development 132, 913–923. doi: 10.1242/dev.01673

PubMed Abstract | CrossRef Full Text | Google Scholar

Nixon, T. R. W., Richards, A., Towns, L. K., Fuller, G., Abbs, S., Alexander, P., et al. (2019). Bone morphogenetic protein 4 (BMP4) loss-of-function variant associated with autosomal dominant Stickler syndrome and renal dysplasia. Eur. J. Hum. Genet. 27, 369–377. doi: 10.1038/s41431-018-0316-y

PubMed Abstract | CrossRef Full Text | Google Scholar

Ohno-Matsui, K., Kawasaki, R., Jonas, J. B., Cheung, C. M., Saw, S. M., Verhoeven, V. J., et al. (2015). International photographic classification and grading system for myopic maculopathy. Am. J. Ophthalmol. 159, 877–883.e7. doi: 10.1016/j.ajo.2015.01.022

PubMed Abstract | CrossRef Full Text | Google Scholar

Ohno-Matsui, K., Lai, T. Y., Lai, C. C., and Cheung, C. M. (2016). Updates of pathologic myopia. Prog. Retin. Eye Res. 52, 156–187. doi: 10.1016/j.preteyeres.2015.12.001

PubMed Abstract | CrossRef Full Text | Google Scholar

Rausch, R. L., Libby, R. T., and Kiernan, A. E. (2018). Ciliary margin-derived BMP4 does not have a major role in ocular development. PLoS One 13:e0197048. doi: 10.1371/journal.pone.0197048

PubMed Abstract | CrossRef Full Text | Google Scholar

Reis, L. M., Tyler, R. C., Schilter, K. F., Abdul-Rahman, O., Innis, J. W., Kozel, B. A., et al. (2011). BMP4 loss-of-function mutations in developmental eye disorders including SHORT syndrome. Hum. Genet. 130, 495–504. doi: 10.1007/s00439-011-0968-y

PubMed Abstract | CrossRef Full Text | Google Scholar

Sankaridurg, P., Tahhan, N., Kandel, H., Naduvilath, T., Zou, H., Frick, K. D., et al. (2021). IMI impact of Myopia. Invest. Ophthalmol. Vis. Sci. 62:2. doi: 10.1167/iovs.62.5.2

PubMed Abstract | CrossRef Full Text | Google Scholar

Spaide, R., Ohno-Matsui, K., and Yannuzzi, L. (2021). Pathologic Myopia. Invest. Ophthalmol. Visual Sci. 62:5.

Google Scholar

Sun, W., Xiao, X., Li, S., Ouyang, J., Li, X., Jia, X., et al. (2019). Rare variants in novel and known genes associated with primary angle closure glaucoma based on whole exome sequencing of 549 probands. J. Genet. Genom. 46, 353–357. doi: 10.1016/j.jgg.2019.06.004

PubMed Abstract | CrossRef Full Text | Google Scholar

Takenouchi, T., Nishina, S., Kosaki, R., Torii, C., Furukawa, R., Takahashi, T., et al. (2013). Concurrent deletion of BMP4 and OTX2 genes, two master genes in ophthalmogenesis. Eur. J. Med. Genet. 56, 50–53. doi: 10.1016/j.ejmg.2012.10.007

PubMed Abstract | CrossRef Full Text | Google Scholar

Thanikachalam, S., Hodapp, E., Chang, T. C., Swols, D. M., Cengiz, F. B., Guo, S., et al. (2020). Spectrum of genetic variants associated with anterior segment dysgenesis in South Florida. Genes (Basel) 11:350. doi: 10.3390/genes11040350

PubMed Abstract | CrossRef Full Text | Google Scholar

Thompson, A., Berry, M., Logan, A., and Ahmed, Z. (2019). Activation of the BMP4/Smad1 pathway promotes retinal ganglion cell survival and axon regeneration. Invest. Ophthalmol. Vis. Sci. 60, 1748–1759. doi: 10.1167/iovs.18-26449

PubMed Abstract | CrossRef Full Text | Google Scholar

Tideman, J. W. L., Pärssinen, O., Haarman, A. E. G., Khawaja, A. P., Wedenoja, J., Williams, K. M., et al. (2021). Evaluation of shared genetic susceptibility to high and low Myopia and Hyperopia. JAMA Ophthalmol. 139, 601–609. doi: 10.1001/jamaophthalmol.2021.0497

PubMed Abstract | CrossRef Full Text | Google Scholar

Wang, P., Li, S., Sun, W., Xiao, X., Jia, X., Liu, M., et al. (2019). An ophthalmic targeted exome sequencing panel as a powerful tool to identify causative mutations in patients suspected of hereditary eye diseases. Transl. Vis. Sci. Technol. 8:21. doi: 10.1167/tvst.8.2.21

PubMed Abstract | CrossRef Full Text | Google Scholar

Wang, Q., Wang, P., Li, S., Xiao, X., Jia, X., Guo, X., et al. (2010). Mitochondrial DNA haplogroup distribution in Chaoshanese with and without Myopia. Mol. Vis. 16, 303–309.

Google Scholar

Wong, T. Y., Ferreira, A., Hughes, R., Carter, G., and Mitchell, P. (2014). Epidemiology and disease burden of pathologic myopia and myopic choroidal neovascularization: an evidence-based systematic review. Am. J. Ophthalmol. 157, 9–25.e12. doi: 10.1016/j.ajo.2013.08.010

PubMed Abstract | CrossRef Full Text | Google Scholar

Yi, Z., Ouyang, J., Sun, W., Li, S., Xiao, X., and Zhang, Q. (2020). Comparative exome sequencing reveals novel candidate genes for retinitis pigmentosa. EBioMedicine 56:102792. doi: 10.1016/j.ebiom.2020.102792

PubMed Abstract | CrossRef Full Text | Google Scholar

Zhang, Q. (2021). “Genetics of pathologic Myopia,” in Pathologic Myopia, eds R. F. Spaide, K. Ohno-Matsui, and L. A. Yannuzzi (Cham: Springer International Publishing), 43–58.

Google Scholar

Keywords: pathologic myopia, early-onset myopia, BMP4, truncation variants, microphthalmia
