Abdelfettah Belhabib, Mohamed Boulouird, Moha M’Rabet Hassani, "Smart Switching StrategyBased Supervision Rule to Mitigate the Problem of Pilot Contamination in Massive MIMO Systems", Wireless Communications and Mobile Computing, vol. 2020, Article ID 8868597, 13 pages, 2020. https://doi.org/10.1155/2020/8868597
Smart Switching StrategyBased Supervision Rule to Mitigate the Problem of Pilot Contamination in Massive MIMO Systems
Abstract
Despite the large benefits that can be fulfilled through the exploitation of Massive Multiinput Multioutput (MMIMO), this technology still constrained by a wellknown constraint, called as pilot contamination problem (PCP), which is the main consequence of, simultaneously, reusing the same set of orthogonal pilot sequences (OPSs) for the users of several cells. Due to the scarcity of the OPS resources, the reuse of the same set of the OPSs for the users of different cells is unavoidable. Hence, this work proposes a novel decontaminating strategy, which is aimed at guaranteeing a tradeoff between the use of the OPSs and the mitigation of the PCP. Specifically, to make the use of the available OPSs better, we propose the consolidation of two powerful decontaminating strategies. Under a derived supervision rule (SR), these strategies are the soft pilot reusebased multicell block diagonalization precoding (SPRMBDP) and the weighted graph coloringbased pilot assignment (WGCPA). The SR enables the switching mechanism between the two strategies, which leads to address the PCP with a fewer number of the OPSs compared to the SPRMBDP, therefore boosting the percell achievable rate. Simulation results prove the effectiveness of our proposed strategy.
1. Introduction
MMIMO technology was introduced in 2010 by [1], and it is aimed at serving, simultaneously, tens of the users ( user per cell). This is by employing a massive number (i.e., hundreds) of antennas (i.e., antennas) at the Base Stations (BSs). This relevant technology has large benefits [2]. Thus, as the number of antennas deployed in the BSs goes to the infinity, the noisy components and the intracell interferences are made small [1], and the transmit power is reduced through a beamforming technique, which contributes to boosting the energy efficiency [3]. The MMIMO technology has been matured and adapted to the fifthgeneration (5G); this is with a finite number of antennas , and it has been commercialized in the sub6 GHz bands [4]. However, this is not the end of the MMIMO, because its large benefits are not yet fully achieved, and still constrained by the PCP [4] (Figure 1).
The reuse of the same set of the OPSs, across different cells, leads to the problem of intercell interferences. To avoid this problem, each user should be assigned a specific pilot sequence; in other words, the users of all cells must be assigned with a set of OPSs. However, this is not possible due to the scarcity of the available set of OPSs; consequently, the reuse of the same set of OPSs across different cells is unavoidable; hence, the PCP will emerge between the users that employ the same OPSs. Consequently, the channel state information (CSI) will be, inaccurately, estimated and the whole process of communication between the users and the BSs will be dramatically damaged [5].
Since the appearance of MMIMO, a large body of research has been carried out to deal with the PCP. A timeshiftedbased strategy has been proposed in [6, 7], which proposes to insert a delay between the phases of communication of the adjacent cells; meanwhile, some of them perform in the data transmission phase; the others are obliged to perform in the pilot transmission phase. However, the estimated CSI at the BSs becomes contaminated by the transmitted data in adjacent cells instead of being contaminated by the pilot sequences. Based on the singular value decomposition (SVD), the null space of interference was exploited to schedule the data signals toward their desired target (i.e., users) [8, 9]. Indeed, extra pilot resources are required to accurately identify the null space of interferences. The space signatures were suggested to spatially identify the desired signals based on their angle of arrivals (AoAs); therefore, the same OPSs are allocated to the users having nonoverlapped AoAs [10, 11]. Nevertheless, a nonoverlapping AoA is assumed which does not necessarily hold in practice.
Optimizationbased decontamination strategy was suggested to boost the qualityofservices (QoS) for the overall users [12–14]. Specifically, the proposal of [12] is aimed at finding out the optimal pilot assignment scheme, that is, through maximizing the sum rate within cells, while [13] focuses on assigning OPSs to the users of adjacent cells, which are suffering from a severe influence of the PCP; in [14], the users within cells are divided, based on their signaltointerferenceplusnoise ratio (SINR), and those having a low SINR are optimally assigned with OPSs.
A weighted graph coloringbased pilot assignment (WGCPA) decontaminating strategy is proposed in the work of [15], which is aimed at reducing the strength of the PCP upon the users that employ the same OPSs; this is through the employment of the graph coloring theory. The WGCPA has been coupled with the soft pilot reuse (SPR) strategy in the work of [16, 17], which was, only, focused on the uplink phase. Specifically, [16] proposed to enhance the performance of edge users based on the SPR, while the slight contamination among the center users is addressed based on the WGCPA. In [17], users within cells are split into three groups, and the problem of the PCP upon the two groups is separately addressed based on the WGCPA and the SPR strategies, while the PCP upon the group of the center users is neglected.
Regarding the fact that the center users are close to the BSs, they benefit from a high QoS compared to the edge users, which are facing a severe degree of the PCP that comes from the edge users of the adjacent cells. To guarantee the fairness between the users of each cell, it is necessary to enhance the QoS of the edge users. Accordingly, a soft pilot reusebased multicell block diagonalization precoding (SPRMBDP) was proposed in [9], which suggests selecting the edge users of the overall cells; therefore, each one of the selected users is assigned with a unique OPSs, while the center users of the overall cells are obliged to reuse the same set of the OPSs (i.e., full pilot reuse); therefore, by exploiting the singular value decomposition (SVD) tool, data symbols are scheduled toward the target users. That is through a null subspace of the PCP. However, the problem of pilot overhead can damage the fulfilled performance of the SPRMBDP [9], due to its requirement for extra OPSs.
In the existing decontaminating strategies, less attention has been paid to the problem of pilot overhead, which is—without any doubt—a crucial side that must be respected in any proposed decontaminating strategy; stand from that remark, this paper provides a new decontaminating strategy to boost the performance of the MMIMO. Specifically, to ensure a tradeoff between the use of the OPSs and the mitigation of the PCP, we propose the consolidation of the SPRMBDP and the WGCPA. This is under a derived supervision rule (SR) that economizes and controls the use of the precious OPSs while trying to overcome the PCP. The proposed strategy is referred to as a smart switching strategybased supervision rule (S3SR). In a nutshell, the prime contribution of the present paper can be summarized as follows: (i)A novel S3SR strategy is proposed to deal with the PCP in MMIMO(ii)To ensure a tradeoff between the use of OPSs and the mitigation of the PCP, the proposed S3SR is automatically updated based on the SR, which is a new approach that can be exploited to deal with the PCP(iii)Significant improvements are achieved and proved through simulation results
To the best of our knowledge, no prior work has analyzed the S3SR strategy based on the consolidation of the SPRMBDP and the WGCPA strategies in the multicell MMIMO system.
This paper is organized as follows: Section 2 presents the system model adopted in this work. Section 3 sheds light on the communication schemes and reviews of the influence of PCP upon MMIMO systems; therefore, Section 4 presents the proposed S3SR strategy. Section 5 provides the simulation results which prove the effectiveness of the proposed S3SR strategy compared to WGCPA, SPRMBDP, and the conventional strategy [1]. Finally, Section 6 summarizes the prime contribution of this work.
To facilitate the numerical analysis, the following terminologies are considered: the cardinality of a set, the transpose conjugate (i.e., Hermitian), the transpose, the conjugate, and the pseudoinverse are, respectively, denoted as , , , , and . The identity matrix is denoted as , while refers to the user of the cell. The Frobenius norm of a matrix is denoted as .
2. System Model
This section is aimed at presenting the system model, which is adopted in this paper. Hence, a multicell MMIMO system is considered which is composed of hexagonal cells. Each cell is equipped with a centered BS of antennas, and singleantenna users [1, 9, 15]. The channel vector that links the user of the cell (i.e., ) to the BS of the cell can be expressed as follows: where denotes the small scale fading (SSF) vector. The SSF vectors of the users are statistically independent and follow a complex Gaussian distribution of zeromean vector and a covariance matrix ; therefore, . The second coefficient refers to the largescale fading (LSF) coefficient, which accounts for the path loss and the shadow fading. The LSF in (1) can be expressed [2, 4, 9, 10, 15, 18] as follows: where denotes the distance between and the BS of the cell, refers to the shadowfading factor, and it has a lognormal distribution (i.e., ) that follows a zeromean Gaussian distribution, which is characterized by a standard deviation , while denotes the cell radius and represents the path loss exponent. The channel matrix between the users of the cell to the BS of the cell can be expressed as where is a diagonal matrix, which includes the LSF coefficients of the users of the cell to the BS of the cell.
2.1. The Pilot Sequences and Their Utility
In order to shed light on the concept of the OPSs, which is one of the fundamentals of the wireless communication systems, let’s assume that a user of cell is assigned with a pilot sequences of length , whereas a user of the same cell is assigned with the pilot sequences of length . To estimate the channel vector of the two users at the BS of cell , the two users uplink their corresponding pilot sequences; therefore, the BS of cell exploits the received pilot signals and the orthogonality condition to estimate the channel of each user. This is through correlating the received pilot signals with the pilot sequences. The orthogonality condition is expressed as follows: where is the delta function, which is expressed as
Hence, to avoid the PCP, each user—of the overall cells—should be assigned with an OPS, which would require OPSs to serve the users of the considered cells. Due to the problem of the pilot overhead, using that number of pilots is not allowed.
2.2. The Problem of Pilot Overhead
Under the blockfading channel model, based timedivisionduplex (TDD) protocol, the communication between the users and their supported BSs can be split into coherence time intervals (i.e., frames) (Figure 2), where the channel responses remain constant. Therefore, at the beginning of each frame, the users uplink their pilot sequences of length . To avoid the intracell interference, the users that belong to the same cell are allocated with OPSs, which requires orthogonal pilot sequences.
To reduce the PCP, extra orthogonal pilot sequences can be used at the expense of shrinking the bandwidth left for data transmission, this problem is what we call the problem of pilot overhead, and it is expressed by the ratio . In other words, increasing the number of OPSs—used for channel training—leads to reduce the subframe of the data transmission (Figure 2).
2.3. Asymptotic Orthogonality
Let , be two vectors, which are mutually independent, where and . Hence, the asymptotic orthogonality condition can be expressed as in [3, 9, 19] as
The given of (6) is the foothold of the MMIMO technology, where the channel vectors become mutually orthogonal for . Hence, the LSF can be exploited to describe the channel of each user, instead of using the SSFs, which varies quickly and hard to be exploited.
3. Communication Schemes and the Effect of Pilot Contamination
This section is aimed at analyzing the different processes of the wireless communication between the users and their respective BSs, therefore showing the main influence of the PCP on the fulfilled performance of the MMIMO. Thus, the widely adopted blockfading channel model, based TDD protocol, is considered [4, 9, 15, 20], where the channel responses remain constant. Thus, three specific phases can be distinguished: channel estimation through uplink training, data detection, and data precoding. Therefore, by adopting the system model presented in Section 2, these three phases are provided in the following subsections.
3.1. Training Phase and Channel Estimation
During the training phase, the users of each cell, synchronously, uplink their pilot sequences of length . Thus, the received pilot signal at the BS of the cell can be expressed as where represents the transmitted power, which is used by each user to uplink its pilot sequences; is the pilot sequences of the user, where the orthogonality condition is satisfied [21, 22]; is an additive white Gaussian noise (AWGN) at the antennas BS of the cell. Therefore, by correlating the received pilot signal , with the local pilot sequences , the estimated channel of at the BS of the cell is expressed as
3.2. Data Detection
Users of each cell uplink their data symbols. Accordingly, the user uplink its data symbols , where . Therefore, the received data signal at the BS of the cell can be expressed as where denotes the AWGN at the antennas BS of the cell. Therefore, based on the matchedfilter (MF) detector (i.e., maximum ratio combining) [23], the estimated data symbols of the user , at the BS of the cell, can be computed as follows: where arranges the interference and the noisy components, and it is expressed as
Therefore, the uplink SINR of can be expressed as
Hence, the corresponding average uplink achievable rate is then expressed as where denotes a parameter that evaluates the decrease of the spectral efficiency, which is caused by the problem of pilot overhead. It is well seen from (12) that the saturates (i.e., tends to constant value however how larger the number of antennas deployed at the BSs) when the number of the antennas BSs tends toward the infinity, which is inconsistent with the main goal of the MMIMO technology, which is aimed at enhancing the system throughput; this is by using a massive number of antennas at the BSs.
3.3. Data Precoding
The data symbols of the users are precoded at the BSs before being transmitted toward the users. Accordingly, based on the MF precoder, the data symbols of are precoded at the BS of the cell. This is based on the following precoder: where is a normalization factor. Therefore, the received data signal at can be expressed as
Here, the transmit power on the downlink phase is denoted as , while denotes the interference components, which can be expressed as
Thus, the downlink SINR of can be expressed as follows:
Therefore, the average downlink achievable rate can be expressed similarly to (13) as follows:
It is well seen from (12) and (17) that the fulfilled SINR is saturated. Specifically, by increasing the number of antennas toward the infinity, the fulfilled SINR remains constant; hence, it is said to be saturated in a fixed value, which is inconsistent with the main target of MMIMO. Thus, to benefit from the MMIMO, the increases of should be accompanied by the increases of the fulfilled SINR. It should be noticed that the saturation of the SINR, in the asymptotic regime (i.e., ), is mainly caused by the PCP.
4. Proposed S3SR
Since the LSF coefficients are not the same for different users, and the QoS of a user depends on its LSF coefficient (e.g., (12)); the users of each cell benefit from an unfair QoS. Accordingly, the users of each cell are separated into two groups, which are called the center and edge users; therefore, to control the use of the OPSs while mitigating the PCP upon the users of each group, a BS controller is exploited to compute the SR, which is employed to make better use of the OPSs while making the decision on which strategy of the two strategies (i.e., SPRMBDP or the WGCPA) is desired to be used to mitigate the PCP upon the users of each group (i.e., center and edge users). This process is described in detail in the following subsections.
4.1. User Classification
The users of each cell are randomly distributed and have different LSF coefficients. Thus, by exploiting their respective LSF coefficients, the users of the cell can be classified at the aim of the following threshold: where denotes a weighted parameter, which is exploited to adjust regarding the system configuration. Thus, for , the users are viewed as center users, while they are considered as edge users for . Therefore, the user is classified based on its LSF coefficient as follows:
4.2. Supervision Rule
In order to construct the SR, the number of edge and center users is, separately, computed in each cell. Thus, the number of edge and center users of the cell is computed based on (19) and (20) as follows:
and so on for the cells (i.e., ). Therefore, each BS compute and transmit its number of center and edge users to the BS controller, which is in charge of computing the total number of edge users and center users , which are wandering in the cells, that is as follows:
Hence, the derived SR at the BS controller can be expressed as follows:
As the SPRMBDP strategy requires much OPSs (i.e., ) compared to those required by the WGCPA strategy (i.e., ). The SR (23) obligates the BSs to apply the SPRMBDP to the group of users ( or ), which requires less number of the OPSs, while the WGCPA is applied to the other set of users (i.e., unserved users by the SPRMBDP). Accordingly, the SR is aimed at using the SPRMBDP and the WGCPA strategies, flexibly, to achieve two specific goals: reducing the problem of pilot overhead and overcoming the PCP.
4.3. The Number of OPSs Required
Referring to (23), the number of OPSs required by the proposed S3SR can be computed as follows:
The number of OPSs required in the conventional SPRMBDP is computed as follows:
To clarify the benefits of the proposed S3SR strategy, let us analyze the example given in Figure 3, which depicts a set of three hexagonal cells (i.e., ). Each cell is equipped with eight, randomly distributed, users (i.e., ). Thus, Figure 3(a) shows the conventional SPRMBDP, where the edge users are assigned with OPSs, while the center users are obliged to reuse OPSs. Accordingly, is the number of the OPSs, which is required by the SPRMBDP to overcome the PCP. However, from Figure 3(a), it is well recognized that the PCP remains upon the center users. Figure 3(b) depicts the conventional WGCPA strategy, which is aimed at reducing the PCP upon the users that employ the same OPSs; however, for a large number of users per cell, the WGCPA tends to perform like a random pilot assignment strategy.
(a)
(b)
(c)
(d)
The two sides of the S3SR are shown in Figures 3(c) and 3(d). Specifically, in Figure 3(c), consequently, the S3SR strategy applies, simultaneously, the SPRMBDP strategy to the edge users, whereas the WGCPA is dedicated to the center users. Therefore, the number of the OPSs, which is required in this case based on (24) is . The second side of S3SR is depicted in Figure 3(d), where , and according to (23), the S3SR strategy applies simultaneously the SPRMBDP strategy to the center users, while the WGCPA strategy is applied to the edge users. Thus, the number of the required OPSs is only OPSs. Still referring to Figure 3(d), the use of the conventional SPRMBDP will need the use of . Thus, the S3SR sacrifices with less OPSs compared to the SPRMBDP.
Since the S3SR supports two cases (23), the same analysis can be, symmetrically, done for both cases. The following analysis is restricted to one side of the S3SR, where (e.g., Figure 3(d)).
4.4. The Allocation of the OPSs
Let be the set of the OPSs (i.e., ), which is required by the S3SR strategy, where . Therefore, can be expressed as where is the set of the OPSs, which is allocated to the users, while denotes the OPSs allocated to the edge users. Since SPRMBDP is selected to be applied to the center users, the set must be shared by the users of the cells. Therefore, it can be split as follows: where denotes the subset of the OPSs, which are allocated to the center users of the cell, and it can be expressed as follows: where denotes the pilot sequences of the center user of the cell. On the other hand, the set of the OPSs , which is reused by the edge users (i.e., , ), can be expressed as where denotes the pilot sequences assigned to the edge user of the cell.
4.5. The WGCPA Applied to the Edge Users
A set of OPSs is, fully, reused by the edge users of the cells. Hence, WGCPA [15] is employed to manage the assignment of the OPSs to the edge users, therefore reducing the strength of the PCP upon these edge users. Specifically, the strength of the PCP between two edge users and (i.e., where and ) that employ the same pilot sequence, i.e., , can be expressed as
Notice that as increases, the strength of the PCP between the users and increases too and vice versa. Therefore, the WGCPA is aimed at reusing the same OPSs for the edge users of different cells, where is minimized. To apply the WGCPA strategy, it is desired first to define an interference graph , where denotes the vertexes of Gr, while denotes the severity of the PCP upon the edge users. Hence, Gr can be expressed similarly to [15] as follows: where , , and x.
4.6. Channel Estimation
During the training phase, the received pilot signal at the BS of the cell can be expressed as where and denote, respectively, the channel matrices of the edge and center users, while is the AWGN at the antennas BS of the cell. It should be noticed that, only, the first rows of are considered when .
Since the SPRMBDP strategy serves the center users, their corresponding channels will be, perfectly, estimated. On the other hand, the WGCPA strategy is dedicated to the edge users of the overall cells. Thus, the strength of the PCP is minimized, upon the edge users. Therefore, the estimated channels at the BS of the cell can be expressed as follows:
Therefore, based on (4), the noisy components in (33), i.e., and , can be canceled. This is by increasing the number of the antennas at the BSs (i.e., ). Notice that only the first column of are considered (33) if .
4.7. Data Detection
Simultaneously, the users of each cell uplink their data symbols. Thus, the received data signals at the BS of the cell can be expressed as follows: where denotes the transmit power during the uplink phase, while and represent, respectively, the data symbols of the center users and those of the edge users of the cell. The AWGN at the antennas BS of the cell is expressed by .
For data detection, let us adopt a lowcomplexity MF detector (i.e., for the center users and for the edge users). Therefore, the detected data symbols can be expressed, separately, for the two groups as follows:
4.7.1. For the Center Users
where denotes the interference terms, and it can be expressed as
Therefore, the detected data symbols of the center user wandering in the cell can be expressed as follows: where refers to the corresponding interference of the center user in the cell. Therefore, the uplink SINR of the center user in the cell is
Based on (6), the denominator of (38) tends toward zero. Consequently, the is significantly boosted, compared to the fulfilled SINR in the conventional (i.e., (12)). Therefore, the average uplink achievable rate, of the center user of the cell, can be expressed similarly to [9] as follows:
4.7.2. For the Edge Users
Similar to (37), denotes the corresponding interferences. Then, the detected data symbol of the edge user wandering in the cell is expressed as follows: where denotes the interference term, which corresponds to the edge user of the cell. Therefore, the uplink SINR of the edge user in the cell is expressed as follows:
Even though (42) looks like the conventional strategy (12), they are not similar. Due to the use of the WGCPA, which is aimed at reducing the interference components in the denominator of (42), hence, the fulfilled SINR is enhanced for the edge users. Therefore, the average uplink achievable rate can be expressed similarly to (39) by replacing by .
4.8. Data Precoding
Before transmitting the data symbols toward the target user, each BS precodes its local data symbols. This is based on a constructed precoder (e.g., MF precoder which is considered herein). Thus, the center users will receive their respective data symbols based on SPRMBDP, while the WGCPA is used for edge users.
4.8.1. For Center Users
From the first line of (33), it is well recognized that the PCP upon the center users is completely canceled. Accordingly, the BSs become able to partially estimate the channel matrices of the center users of the adjacent cells, which are then exploited to find out the subspace spanned by the intercell interference. Therefore, to project data symbols through the null space of interference, this process is explained in more detail in the following.
Let be the matrix that arranges the estimated channels of intercell interferences, which are generated by the center users of the cells to the BS of the cell. Thus, the matrix can be expressed as follows:
Therefore, to find out the directions of the null subspace spanned by , the SVD tool will be exploited. Thus, the matrix of intercell interferences can be expressed as where and denote, respectively, the left and the right singular vector, while refers to the matrix that comprises the singular values and it can be expressed as where denotes the rank of , and is an diagonal matrix of the singular values, which are arranged as follows:
Since is huge compared to the number of the users, the condition is necessarily satisfied. Hence, the null subspace of is spanned by the column of a matrix , which represents the submatrix of and it can be expressed as
Thanks to the SVD tool, the null space of interference is arranged in , which can be exploited to construct the projection operator as follows: where ; therefore, by projecting the conventional MF precoder (14) onto the null subspace of , the new precoder can be expressed as follows:
Therefore, , we have
Hence, based on the enhanced MF precoder (49), the received data signal at the center users wandering in the cell can be expressed as follows: where refers to the data symbols that will be transmitted to the users, while denotes the AWGN at the antennas of the those users. Therefore, the received data signal at the center user of the cell is expressed as follows: where and denote, respectively, the respective data symbols of the user and the AWGN at its antenna. Thereafter, the downlink SINR of the center user in the cell is expressed as where arranges the interference components. Notice that still hold. Therefore, based on (6), the denominator of (53) can be forced towards zero, which proves that the SINR is significantly boosted, and the average downlink achievable rate, in this case, is expressed as
4.8.2. For the Edge Users
Regarding the fact that the estimated channels of the edge users (i.e., second line of (33)) appear like those derived in the conventional strategy (8), hence, the same analysis given in Subsection 3.3 can be similarly done for the edge users. Thus, the downlink SINR of the edge user in the cell is then:
Therefore, the average downlink achievable rate for the edge user in the cell is then expressed as where denotes a parameter that evaluates the decrease of the spectral efficiency, which is caused by the problem of pilot overhead.
5. Simulation Results
This section is aimed at evaluating the performance of the proposed S3SR. That is through a set of Monte Carlo simulation applied to the typical multicell structure, which is described in Section 2, where the users are randomly distributed within each cell. The specific parameters used in this work are listed in Table 1.

Figure 4 shows the average uplink achievable rate versus the number of antennas deployed in the BSs. As can be recognized from Figure 4, the superiority of the proposed S3SR is well seen compared to the other strategies (i.e., conventional, SPRMBDP, and WGCPA), especially for a large number of antennas , where the gap is increased. On the other hand, the fulfilled performance by the SPRMBD is too close to those achieved by the WGCPA, owing to the problem of pilot overhead (Table 2). Furthermore, based on Table 2 where , we notice that the S3SR performs better than the SPRMBDP, even if they employ the same number of the OPSs, that proves the effectiveness of the proposed S3SR over the conventional strategies.
The average downlink achievable rate versus is depicted in Figure 5, where the superiority of the S3SR compared to the WGCPA is started from a large number of antennas; specifically, from , the S3SR performs better compared to the other strategies.
In order to show the robustness of the S3SR versus different distribution of the users within cells, which is controlled by the value of , Figure 6 depicts the mean square error (MSE) [9] of the estimated channels versus . The MSE can be expressed as
