Xuan Jiang
Li Hu1†
Xiaoxi Lin- 1Department of Plastic and Reconstructive Surgery, Shanghai Ninth People’s Hospital, Shanghai Jiao Tong University School of Medicine, Shanghai, China
- 2Department of Laser and Aesthetic Medicine, Shanghai Ninth People’s Hospital, Shanghai Jiao Tong University School of Medicine, Shanghai, China
Introduction: Synovial sarcoma (SS) is one of the most prevalent malignant soft tissue sarcomas in children and adolescents. Pediatric populations often present with atypical features, complicating the differentiation from benign intramuscular venous malformations (VMs).
Case presentation: An 11-year-old male with a four-year history of progressive right plantar pain and a compressible intramuscular mass. The initial magnetic resonance imaging (MRI) findings suggest VM, due to high signal in T2-weighted images. Sclerotherapy under digital subtraction angiography (DSA) revealed unexpected hyper-vascularity, prompting surgical exploration. Histopathology demonstrated spindle and epithelioid cells with hemangiopericytoma-like morphology and mitotic activity, while SS18-SSX1 gene rearrangement confirmed SS. Chemotherapy was then administered, without recurrence over two years.
Conclusion: SS may clinically and radiographically mimic benign vascular anomalies, particularly in children. Discrepancies in vascular dynamics on DSA and atypical imaging features warrant suspicion for malignancy. Early histopathological validation is critical to prevent diagnostic delays, optimize multimodal therapy, and improve outcomes in this aggressive tumor.
Introduction
Synovial sarcoma is an aggressive malignancy accounting for 10-20% of soft tissue sarcomas in adolescents and young adults, with a median diagnostic age of 35 years. Approximately 70% of cases demonstrate a predilection for extremity involvement, particularly in the lower limbs (1). Clinically, SS manifests as a slowly enlarging, painful intramuscular mass, often misinterpreted as benign lesions due to its indolent progression. Early symptoms include localized tenderness and functional impairment, while advanced stages may present with neurovascular compression or restricted mobility (2). MRI serves as the modality of choice for SS evaluation, providing superior soft tissue contrast differentiation, multiplanar lesion characterization, and precise delineation of neurovascular bundle infiltration and lymphatic dissemination (3). Diagnostic imaging reveals T2-weighted hyperintense lesions on MRI, frequently misattributed to VMs, in which case histopathological confirmation is necessary. Definitive diagnosis relies on identifying biphasic spindle-epithelioid cell morphology and SS18-SSX fusion gene detection. The main treatment for SS is wide surgical excision with adjuvant or neoadjuvant radiotherapy, and chemotherapy, while SS is moderately sensitive to cytotoxic chemotherapy with agents such as ifosfamide and anthracyclines (4).
We report a case of an 11-year-old male with clinical symptoms and imaging features similar to VM who received related treatment.
Case presentation
An 11-year-old male had a four-year history of right plantar pain worsening progressively, and an intramuscular mass enlarging gradually which had no obvious inducement. Limping occurred about 1 year ago. He has gained weight as child of the same age since the onset. On physical examination, a soft and compressible mass was found in the right plantar region, with no obvious boundary, pulsation, or paresthesia. A high-signal intensity mass on T2-weighted fat-suppression images was revealed through MRI, suggesting vascular origin (Figure 1). He was diagnosed as intramuscular VM.
Figure 1. Patient diagnosis and management. The patient presented with a painful mass in right plantar (A). MRI revealed a high signal on T2-weighted enhanced sequence (B). The initial diagnosis was venous malformation, and sclerotherapy under DSA was performed, followed by surgical excision (C). Pathological biopsy of the lesion was subsequently established (D).
Considering the preliminary diagnosis, the patient underwent sclerotherapy under DSA. However, the lesion showed hyper-vascularity during the procedure, which was inconsistent with the slow-flow characteristics of VMs, raising suspicion for a different pathology possibility.
Consequently, surgical exploration was conducted to obtain a definitive diagnosis. A yellowish white lipoid frail soft tissue was found below flexor digitorum brevis and abductor hallucis. Both the surrounding muscles and fascia spaces were involved and no obvious boundary was observed (Figure 1). Pathological sections showed the cell characteristics of the mesenchymal malignant tumor tissue, including spindle cells and epithelial cells. Hemangiopericytoma like image and mitotic figures could be seen (Figure 2). Immunohistochemical analysis demonstrated positivity for SS-characteristic markers, including diffuse positivity for TLE1 and focal positivity for both CK and CK7. The discovery of fluorescence in situ hybridization (FISH) showed the SS18 (18q11) gene rearrangement, confirming the diagnosis of SS.
Figure 2. Histology of spindle cell synovial sarcoma of right plantar. The tumor is mesenchymal malignancy, characterized by a mix of spindle-shaped and epithelioid cells. Hemangiopericytoma like image and mitotic figures can be observed. The figure demonstrates H&E-stained sections at magnifications of 100× (A) and 200× (B).
After confirming the diagnosis, extended resection was performed. Moreover, chemotherapy was initiated with a VAC regimen (vincristine, actinomycin D, and cyclophosphamide), administered six cycles over six months. The patient tolerated the treatment well, with relief of pain and no notable adverse effects. No recurrence was observed during the two years of follow-up.
Discussion
Distinguishing intramuscular SS from VM is a significant diagnostic challenge, especially in pediatric patients who often present atypically. Intramuscular VMs are benign vascular anomalies characterized by dilated, endothelium-lined venous channels embedded within muscle tissue. Typically, these lesions are soft, compressible masses (5). MRI usually show hyperintensity on T2-weighted sequence (6). SS is a neoplasm originating from mesenchymal tissue, often show similar clinical and imaging features that can be confused with benign conditions like VMs. SS typically present as soft, often tender masses; however, unlike venous malformations, they are generally non-compressible. In SS, a heterogeneous appearance on MRI frequently appears, with high T2 signal due to cystic changes. VM exhibit progressive heterogeneous enhancement, whereas SS typically demonstrates homogeneous enhancement. Moreover, unlike VMs, significant enhancement on contrast imaging and hyper-vascular response on DSA is shown in SS. These are important characteristics for raising suspicion in the case and called for further investigation, as the initial diagnosis based on only imaging was misleading (7).
Histopathological analysis remains the gold standard for SS diagnosis. The SS18 (18q11) gene rearrangement is a hallmark of SS and provides a definitive diagnostic criterion (8). Since SS is a highly aggressive tumor, it’s necessary to make early accurate diagnoses so that appropriate treatments can be arranged as quickly as possible. Delays in diagnosis, as seen in cases initially misdiagnosed as benign entities, can result in disease progression and worse prognose (9).
The optimal management of extremity soft tissue sarcomas needs establishing a definitive pathological diagnosis preoperatively whenever possible, supported by detailed imaging to delineate the tumor’s relationship with surrounding tissues prior to formulating a surgical strategy (10, 11). Based on oncological surgical principles, specifically achieving a R0 resection, remains the cornerstone of treatment, as wide excision significantly reduces both local recurrence rates and mortality (10, 11). If R0 resection cannot be attained, neoadjuvant chemotherapy and/or radiotherapy is warranted. Doxorubicin (ADM) and Ifosfamide (IFO) represent the foundational chemotherapeutic agents for soft tissue sarcomas, while pediatric patients, demonstrating greater chemosensitivity, often derive significant benefit from the VAC regimen (11, 12). Prognosis is determined by factors such as post-treatment recurrence, metastasis occurrence, and time to disease progression, with the initial tumor stage, histological grade, and adequacy of initial therapy being primary determinants influencing recurrence and metastatic risk (11).
Conclusion
This case is remarkable as it emphasizes the potential defects of relying only on non-invasive imaging for soft tissue masses, particularly in pediatric patients whose malignancies are less commonly suspected. For patients with MRI features mimicking VMs, biopsy should be performed to obtain a definitive histopathological diagnosis to differentiate from soft tissue tumors.
Data availability statement
The original contributions presented in the study are included in the article/supplementary material. Further inquiries can be directed to the corresponding authors.
Ethics statement
The studies involving humans were approved by Ethics Committee of the Ninth People’s Hospital Affiliated to Shanghai Jiaotong University School of Medicine. The studies were conducted in accordance with the local legislation and institutional requirements. Written informed consent for participation in this study was provided by the participants’ legal guardians/next of kin. Written informed consent was obtained from the individual(s), and minor(s)’ legal guardian/next of kin, for the publication of any potentially identifiable images or data included in this article.
Author contributions
XJ: Visualization, Investigation, Writing – review & editing, Writing – original draft. LH: Data curation, Writing – review & editing, Conceptualization, Writing – original draft. HC: Methodology, Writing – review & editing, Funding acquisition, Resources. XY: Funding acquisition, Resources, Writing – review & editing, Validation, Supervision, Methodology. XL: Resources, Funding acquisition, Methodology, Supervision, Writing – review & editing.
Funding
The author(s) declare that no financial support was received for the research and/or publication of this article.
Conflict of interest
The authors declare that the research was conducted in the absence of any commercial or financial relationships that could be construed as a potential conflict of interest.
Generative AI statement
The author(s) declare that no Generative AI was used in the creation of this manuscript.
Any alternative text (alt text) provided alongside figures in this article has been generated by Frontiers with the support of artificial intelligence and reasonable efforts have been made to ensure accuracy, including review by the authors wherever possible. If you identify any issues, please contact us.
Publisher’s note
All claims expressed in this article are solely those of the authors and do not necessarily represent those of their affiliated organizations, or those of the publisher, the editors and the reviewers. Any product that may be evaluated in this article, or claim that may be made by its manufacturer, is not guaranteed or endorsed by the publisher.
References
1. Nielsen TO, Poulin NM, and Ladanyi M. Synovial sarcoma: recent discoveries as a roadmap to new avenues for therapy. Cancer Discov. (2015) 5:124–34. doi: 10.1158/2159-8290.CD-14-1246
2. Ichinose H, Wickstrom JK, Hoerner HE, and Derbes VL. The early clinical presentation of synovial sarcoma. Clin Orthop Relat Res. (1979) 142:185–9. doi: 10.1097/00003086-197907000-00031
3. McCarville MB, Spunt SL, Skapek SX, and Pappo AS. Synovial sarcoma in pediatric patients. AJR Am J Roentgenol. (2002) 179:797–801. doi: 10.2214/ajr.179.3.1790797
4. Spurrell EL, Fisher C, Thomas JM, and Judson IR. Prognostic factors in advanced synovial sarcoma: an analysis of 104 patients treated at the Royal Marsden Hospital. Ann Oncol. (2005) 16:437–44. doi: 10.1093/annonc/mdi082
5. Jung R and Trivedi CM. Congenital vascular and lymphatic diseases. Circ Res. (2024) 135:159–73. doi: 10.1161/CIRCRESAHA.124.323181
6. Cao J, Liu J, Zhang X, and Wang Z. A systematic review and network meta-analysis of the effectiveness of sclerotherapy for venous malformation. J Vasc Surg Venous Lymphat Disord. (2023) 11:210–8 e3. doi: 10.1016/j.jvsv.2022.08.004
7. Tordjman M, Honore C, Crombe A, Bouhamama A, Feydy A, Dercle L, et al. Prognostic factors of the synovial sarcoma of the extremities: imaging does matter. Eur Radiol. (2023) 33:1162–73. doi: 10.1007/s00330-022-09049-y
8. Jerby-Arnon L, Neftel C, Shore ME, Weisman HR, Mathewson ND, McBride MJ, et al. Opposing immune and genetic mechanisms shape oncogenic programs in synovial sarcoma. Nat Med. (2021) 27:289–300. doi: 10.1038/s41591-020-01212-6
9. Blay JY, von Mehren M, Jones RL, Martin-Broto J, Stacchiotti S, Bauer S, et al. Synovial sarcoma: characteristics, challenges, and evolving therapeutic strategies. ESMO Open. (2023) 8:101618. doi: 10.1016/j.esmoop.2023.101618
10. Mowery YM, Ballman KV, Hong AM, Schuetze SM, Wagner AJ, Monga V, et al. Safety and efficacy of pembrolizumab, radiation therapy, and surgery versus radiation therapy and surgery for stage III soft tissue sarcoma of the extremity (SU2C-SARC032): an open-label, randomised clinical trial. Lancet. (2024) 404:2053–64. doi: 10.1016/S0140-6736(24)01812-9
11. NCCN. Guideline For Patients (2024). Available online at: https://www.nccn.org/patientguidelines (Accessed August 16, 2025).
12. Robert C, Kicinski M, Dutriaux C, Routier E, Govaerts AS, Buhrer E, et al. Combination of encorafenib and binimetinib followed by ipilimumab and nivolumab versus ipilimumab and nivolumab in patients with advanced melanoma with BRAF(V600E) or BRAF(V600K) mutations (EBIN): an international, open-label, randomised, controlled, phase 2 study. Lancet Oncol. (2025) 26:781–94. doi: 10.1016/S1470-2045(25)00133-0
