Simulating the Integration and Regulation of Human Ia and Ib Reflexes on Musculoskeletal Robot Driven by Pneumatic Artificial Muscles
1. Kyoto University, Kyoto, Japan
2. Osaka Daigaku, Suita, Japan
Select one of your emails
You have multiple emails registered with Frontiers:
Notify me on publication
Please enter your email address:
If you already have an account, please login
You don't have a Frontiers account ? You can register here
Abstract
Simulations of human Ia and Ib reflexes on a bio-inspired musculoskeletal robot driven by pneumatic artificial muscles (PAMs) offers an attractive option to counter disturbances in complex and dynamical work environments, providing a solution to the significant computational burdens that undermine its potential due to PAMs' inherent non-linearities. This research focuses on the simultaneous integration of human Ia and Ib reflexes(referred to as double-reflex) as countermeasures against physical disturbance in a musculoskeletal robot system driven by PAMs. The system's performance was examined, and implementation challenges were identified during experiments. Mechanisms were then applied to ensure the effective functioning of the integrated reflexes. Experimental results substantiated the effectiveness of the double-reflex system, highlighting its functionality within the robotic system. This investigation corroborates the viability of concurrently implementing Ia and Ib reflexes and provides a reference for the design of robotic reflex control systems. The study also offers some reference, from the view of signal processing, about the possible functions of the human spinal cords that might be necessary to arrange proper reflex actions.
Summary
Keywords
Bio-inspiredRobot, double-Reflex control system, Local reflex control, Musculoskeletal robot, Pneumatic Artificial Muscles, Robotics
