Original Research ARTICLE

Front. Plant Sci., 24 January 2019 | https://doi.org/10.3389/fpls.2019.00025

Bacillus subtilis PTA-271 Counteracts Botryosphaeria Dieback in Grapevine, Triggering Immune Responses and Detoxification of Fungal Phytotoxins

Patricia Trotel-Aziz1*, Eliane Abou-Mansour2, Barbara Courteaux1, Fanja Rabenoelina1, Christophe Clément1, Florence Fontaine1† and Aziz Aziz1†
  • 1Research Unit EA 4707 RIBP, SFR Condorcet FR CNRS 3417, University of Reims Champagne-Ardenne, Reims, France
  • 2Department of Plant Biology, University of Fribourg, Fribourg, Switzerland

Plant pathogens have evolved various strategies to enter hosts and cause diseases. Particularly Neofusicoccum parvum, a member of Botryosphaeria dieback consortium, can secrete the phytotoxins (-)-terremutin and (R)-mellein during grapevine colonization. The contribution of phytotoxins to Botryosphaeria dieback symptoms still remains unknown. Moreover, there are currently no efficient control strategies of this disease, and agro-environmental concerns have raised increasing interest in biocontrol strategies to limit disease spread in vineyards, especially by using some promising beneficial bacteria. Here, we first examined in planta the biocontrol capacity of Bacillus subtilis PTA-271 against N. parvum Np-Bt67 strain producing both (-)-terremutin and (R)-mellein. We then focused on the direct effects of PTA-271 on pathogen growth and the fate of pure phytotoxins, and explored the capacity of PTA-271 to induce or prime grapevine immunity upon pathogen infection or phytotoxin exposure. Results provided evidence that PTA-271 significantly protects grapevine cuttings against N. parvum and significantly primes the expression of PR2 (encoding a β-1,3-glucanase) and NCED2 (9-cis-epoxycarotenoid dioxygenase involved in abscisic acid biosynthesis) genes upon pathogen challenge. Using in vitro plantlets, we also showed that PTA-271 triggers the expression of salicylic acid- and jasmonic acid-responsive genes, including GST1 (encoding a glutathione-S-transferase) involved in detoxification process. However, in PTA-271-pretreated plantlets, exogenous (-)-terremutin strongly lowered the expression of most of upregulated genes, except GST1. Data also indicated that PTA-271 can detoxify both (-)-terremutin and (R)-mellein and antagonize N. parvum under in vitro conditions. Our findings highlight (-)-terremutin and (R)-mellein as key aggressive molecules produced by N. parvum that may weaken grapevine immunity to promote Botryosphaeria dieback symptoms. However, PTA-271 can efficiently attenuate Botryosphaeria dieback by enhancing some host immune responses and detoxifying both phytotoxins produced by N. parvum.

Introduction

Causal agents of grapevine trunk diseases (GTDs) are very damaging for viticulture since their effect leads to plant death, and to date no grape variety is known to be resistant (Surico et al., 2006; Bertsch et al., 2013; Spagnolo et al., 2014; Fontaine et al., 2015; Magnin-Robert et al., 2016). Botryosphaeria dieback, one of the most threatening GTDs (Bertsch et al., 2013), is caused by several Botryosphaeriaceae fungi, including Diplodia seriata, Diplodia mutila, and Neofusicoccum parvum (Úrbez-Torres, 2011; Larignon et al., 2015). Because of the diversity of these hemibiotrophic fungal pathogens and their virulence characters, understanding the interactions that lead to the disease symptomatology is a major challenge in viticulture. Moreover, the virulence of Botryosphaeriaceae is highly variable within the same species, depending on plant tissue, grapevine cultivar, and environmental conditions (Úrbez-Torres, 2011). A common feature is that Botryosphaeriaceae fungi are mainly found in woody tissues but not in leaves, drawing the hypothesis that secreted fungal toxins delocalized via the xylem sap to the leaves could be involved in the emergence of foliar symptoms (Mugnai et al., 1999). Indeed, several secondary metabolites have been characterized in the Botryosphaeriaceae species (Djoukeng et al., 2009; Evidente et al., 2010; Andolfi et al., 2011; Abou-Mansour et al., 2015), and particular attention has been paid to Neofusicoccum spp. regarding its aggressiveness (Úrbez-Torres, 2011). Compounds belonging to two chemical families, the dihydroisocoumarin (R)-mellein and the epoxytoluquinol (-)-terremutin as well as their derivatives are considered as the most phytotoxic (Abou-Mansour et al., 2015). Both (R)-mellein and (-)-terremutin were detected in wood from vines with Botryosphaeria dieback symptoms (Abou-Mansour et al., 2015), and the produced amounts of (R)-mellein were proportional to pathogen aggressiveness (Ramírez-Suero et al., 2014).

(R)-Mellein and its derivatives have been isolated not only from pathogens of grapevine, but also from those of apple, pine, citrus and tomato, and are known for their toxicity in different tissues during plant development (Venkatasubbaiah et al., 1991; Parisi et al., 1993; Cabras et al., 2006; Djoukeng et al., 2009; Evidente et al., 2010). It has been shown that (R)-mellein induced partial necrosis on grapevine leaves and calli (Djoukeng et al., 2009; Ramírez-Suero et al., 2014; Abou-Mansour et al., 2015), and inhibited the growth of wheat embryo culture (Keller et al., 1994). The (R)-mellein derivative methylmellein also exerted a strong antigerminative effect on garden cress (Chooi et al., 2015), while 6-hydroxymellein as a key precursor of (+)-terrein exerted a phytotoxic effect leading to necrotic lesions on fruits (Zaehle et al., 2014; Gressler et al., 2015). (-)-Terremutin and its precursor 6-methylsalicylic acid (6-MSA) as non-host-specific phytotoxins induced necrosis in leaf tissues of grapevine and Arabidopsis thaliana, and showed a mild-antibacterial activity (Venkatasubbaiah et al., 1992; Ding et al., 2010). Similarly, the (-)-terremutin derivative terreic acid also showed an antibacterial activity (Yamamoto et al., 1980; Han et al., 2010) and was suspected to be an important antibiotic compound in soil (Chen et al., 2016). In mammals, terreic acid can affect cell’s immunity (Kawakami et al., 1999).

Attention was further paid to the role of fungal toxin systems in the modulation of the plant immune response leading to plant tolerance or susceptibility to pathogens (Pusztahelyi et al., 2015). In this context, (R)-mellein and (-)-terremutin were shown to induce a late expression of defense-related genes in grapevine calli, including Pathogenesis Related (PR) genes and those involved in the detoxification of reactive oxygen species (Ramírez-Suero et al., 2014; Abou-Mansour et al., 2015), but the extent of these responses remained lower compared to those induced by total extracellular pathogen compounds (Ramírez-Suero et al., 2014). More recently, it has been shown that various defense-related genes are not upregulated in grapevine artificially infected with N. parvum (Reis et al., 2016; Spagnolo et al., 2017). However, in naturally Botryosphaeria-infected grapevine in vineyards, abundant PR proteins and antioxidant enzymes, as well as stilbene accumulation were reported in the brown striped wood (Spagnolo et al., 2014). Similar trends of gene expression and protein upregulation were observed in grapevine leaves infected with another GTDs, namely Esca-complex (Magnin-Robert et al., 2011; Spagnolo et al., 2012). Interestingly, Magnin-Robert et al. (2016) showed the accumulation of (R)-mellein and derivatives in Esca-symptomatic grapevine tissues. However, unlike other pathogens that use specific polyketides as virulence mediators (Uppalapati et al., 2007; Dalmais et al., 2011), to date no relationship was clearly established between (R)-mellein or (-)-terremutin accumulation and modulation of the host immune response.

Grapevine like herbaceous or perennial plants can be colonized by an immense number of microbial organisms in the rhizosphere and aboveground parts (Trotel-Aziz et al., 2008; Pinto et al., 2014; Zarraonaindia et al., 2015). Some of these microorganisms can exert either beneficial or detrimental effects (Möbius and Hertweck, 2009; Schroeckh et al., 2009; Pusztahelyi et al., 2015; Zeilinger et al., 2015, 2016). In asymptomatic and symptomatic GTDs-affected grapevines, the bacterial communities also differed in necrotic and non-necrotic tissues. This microbial shift can impact the tolerance or susceptibility of the vine wood to fungal attacks (Bruez et al., 2015). Indeed, some bacteria belonging to Bacillus spp. (i.e., B. subtilis PTA-271), Pseudomonas spp. and Pantoea spp. isolated from healthy vineyards, are known to induce systemic resistance against the necrotroph Botrytis cinerea (Magnin-Robert et al., 2007; Trotel-Aziz et al., 2008; Verhagen et al., 2011). Beneficial bacteria can directly inhibit pathogen growth and prime plants for enhancing their basal immunity (Verhagen et al., 2004, 2011; Trotel-Aziz et al., 2008; Bakker et al., 2013; Gruau et al., 2015; Aziz et al., 2016). The complex patterns of microbial interactions occurring inside/outside the plant might thus ensure the beneficial outcome of plant association with beneficial/mutualist bacteria in the dieback context. Since 2000, several biocontrol agents have been tested against the numerous pathogens responsible for GTDs, the most efficient to date being antagonistic bacteria and fungi (Haidar et al., 2016; Mondello et al., 2018). For instance, Trichoderma spp. generally showed high efficiency in wound protection against all GTDs pathogens (Di Marco et al., 2002, 2004; John et al., 2008; Halleen et al., 2010) as well as Bacillus spp. (Schmidt et al., 2001; Halleen et al., 2010; Kotze et al., 2011; Rezgui et al., 2016). The benomyl-resistant mutant Fusarium lateritium strain was especially effective as a wound protectant against Eutypa lata (McMahan et al., 2001; John et al., 2005). This strain can degrade in vitro some phytotoxins involved in the expression of foliar symptoms, namely eutypine, 4-hydroxybenzaldehyde, and 3-phenyllactic acid produced by E. lata and pathogens from Esca consortium (Christen et al., 2005). In contrast, the rhizospheric Pythium oligandrum was shown to reduce Phaeomoniella chlamydospora wood necrosis (Esca complex) by stimulating host plant defenses (Benhamou et al., 2012; Yacoub et al., 2016).

Although several biocontrol agents were successfully tested against GTDs pathogens (Mondello et al., 2018), few studies tried to decipher mechanisms involved in plant protection against Botryosphaeria species and their aggressive molecules. Especially, the molecular mechanisms underlying induced protection, and the extent by which beneficial bacteria modulate grapevine immunity and detoxification of the virulent-phytotoxins (R)-mellein and (-)-terremutin, remain largely unknown. In this study, we first examined the capacity of the beneficial bacterium B. subtilis PTA-271 (hereafter PTA-271) to counteract grapevine infection by a N. parvum strain producing both (-)-terremutin and (R)-mellein (namely N. parvum-Bt67). We then focused on the effects of PTA-271 on pathogen’s growth and removal of pure phytotoxins from growth medium. We finally explored the capacity of PTA-271, which was initially isolated from grapevine rhizosphere, to induce or prime grapevine immunity upon pathogen inoculation or after plant exposure to exogenous phytotoxins.

Materials and Methods

Plant Material and Growth Conditions

Three-node-long cuttings of grapevine (Vitis vinifera L., cv. Chardonnay) were collected from 10-year-old plants in Pommery’s vineyards in Reims (France) and kept in a cold chamber at 4°C for 1 month. Cuttings were surface-sterilized with 0.05% cryptonol (8-hydroxyquinoline sulfate) and rooted as described by Lebon et al. (2005). They were placed in 350 mL pots containing the soil Gramoflor Special (Gramoflor GmbH & Co. KG, Vechta, Germany) in a culture chamber (25°C day/night, 60% relative humidity, and 16 h photoperiod at 400 μmoles/m2/s) and watered twice a week. Only cuttings that have developed roots were conserved for further experiments.

Grapevine plantlets (V. vinifera L. cv. Chardonnay, clone 7535) were produced from nodal explants transferred on 15 mL of agar-modified Murashige-Skoog (MS) medium (Trotel-Aziz et al., 2008) in 25-mm test tubes. Plantlets were grown at 25°C day/night, with a 16/8 h photoperiod.

Bacterial Growth and Treatment

Bacillus subtilis PTA-271 (GenBank Nucleotide Accession No. AM293677) was isolated from the rhizosphere of healthy field-grown Chardonnay grapevines in Champagne area, France (Trotel-Aziz et al., 2008). Bacterial growth starts by adding 100 μl of the glycerol stock suspension to sterile Luria Bertani (LB) medium, before incubating at 28°C under continuous shaking (75 rpm). Experiments were performed with the bacteria at the exponential growth phase. After centrifugation (5000 g, 10 min), the pellet was washed once and resuspended in sterile 10 mM MgSO4 medium. Bacterial density was measured by spectrophotometry at 450 and 650 nm, and the mean concentration was adjusted with sterile MgSO4 medium before treatment.

Bacterial suspension was applied twice at the root level of cuttings at a final concentration of 108 cfu/g soil. The first inoculation was performed when cuttings were 8 weeks old and the second inoculation when cuttings were 10 weeks old. Control cuttings were thus similarly drenched twice with MgSO4 solution.

For in vitro-plantlets, bacterial suspension was adjusted to 108 cfu/mL with sterile liquid MS medium then added in new sterile 25-mm culture-tubes (15 mL per tube). Six-week-old plantlets were then transferred in these new tubes for 2 weeks of bacterial treatment in a growth chamber at 22°C with a photoperiod 16/8 h. Control plantlets were transferred in liquid MS medium without bacteria under the same conditions.

Fungal Strain and Growth

The N. parvum strain Np-Bt67 (Reis et al., 2016) isolated from Portuguese vineyards (Estremadura area) is inscribed in HIA collection (Lisbon University, Portugal). Fungi was maintained on potato dextrose agar (PDA, Sigma, Saint-Quentin-Fallavier, France) plates and stored at 4°C. Resulting mycelium was plated on PDA medium and incubated in the dark at 22°C for 7 days before used to inoculate cuttings.

Production and Quantification of Phytotoxins

(R)-mellein (log Kow ∼ 2.5) and (-)-terremutin (log Kow ∼ 0) were extracted and purified from a 10-day-old culture of the Np strain, according to Abou-Mansour et al. (2015). Both toxins were prepared as concentrated stock solutions in sterile MS or 10 mM MgSO4 medium and stored in the dark at 4°C. Before each experiment, daughter solutions were prepared for the biological experiments, and the phytotoxin concentrations were determined before and after treatment using HPLC coupled to a diode array detector (Ultimate 3000 Dual-Gradient, Dionex, Voisins-le-Bretonneux, France). Analyses were done on a C18 reversed phase column (100 mm× 3 mm, 5 μm, Kromasil 100, Dionex) using isocratic elution with acetonitrile (ACN, LC–MS quality, Merck, France) and water (H20) containing 0.1% phosphoric acid (H3PO4). Detection was recorded at 210 and 273 nm for (R)-mellein and (-)-terremutin, respectively. Phytotoxin identification was confirmed by UV spectrum and retention time; (R)-mellein was eluted with 1 mL/min of ACN:H2O 60:40 v/v at 3.8 min, while (-)-terremutin was eluted with 0.7 mL/min of ACN:H2O 10:90 v/v at 5.8 min. Concentration was determined using standard curves.

Fungal Inoculation and Disease Expression

Cuttings pretreated 1 month with bacteria were then wounded (5 mm diameter, 1 mm deep) at 12 weeks old at the second node of the green stem and inoculated with a 3 mm diameter mycelial plug from the 7-day-old culture of Np-Bt67 strain. Inoculation site was then covered with moisten hydrophilic cotton before sealing with parafilm. Without bacteria, cuttings were pretreated 1 month with MgSO4, then pathogen-inoculated also at 12 weeks old using the same method. To confirm that lesions were really due to pathogen infection and not to the injury, controls were inoculated with sterile 3-mm PDA plugs. After inoculation, cuttings were kept in the same culture chamber conditions to quantify Botryosphaeria dieback symptoms at 4 months post-inoculation. As potentially indicative, phytotoxins were also extracted from the same leaf powder (1 g FW in 5 mL of methanol – LC–MS quality, Merck, France for 1 h at 37°C before analysis in supernatant as described below) at least twice in triplicates, and phytotoxins were not detectable in leaves of infected cuttings. At 4 months post-inoculation, symptoms of Botryosphaeria dieback were evaluated by measuring both the canker and necrotic surface area on green shoots as described by Espinosa et al. (2009) and Laveau et al. (2009), and by quantifying the percentage of dead branch for inoculated cuttings.

Evaluation of Direct Effect of B. subtilis PTA-271 on N. parvum Growth

PTA-271 grown in LB medium was inoculated (5 μL drop at 109 cfu/mL) on the one side of a Petri plate (9 cm diameter) containing PDA medium, then incubated at 28°C in the dark. After 24 h, a mycelium plug of 4-day-old pathogenic fungus was co-inoculated on the other side of PDA plates, and the plates were incubated in the same conditions. Controls are PDA plates with a mycelium plug and a LB-drop incubated until mycelial growth reached the edge of the control plate. The same experiment was also performed at 22°C as an optimal temperature for pathogen growth (Trotel-Aziz et al., 2008), while 28°C was optimal for PTA-271 growth. Antagonistic effect was characterized by an inhibition zone around bacterial colony.

Detoxification Assays With B. subtilis PTA-271

PTA-271 was collected at exponential phase in LB medium, diluted to reach a final density of 104 to 2 × 108 cfu/mL, and centrifuged at 5000 g (4°C, 15 min). Pellet was then resuspended either in a sterile MS medium (nutrient rich) or in a 10 mM MgSO4 medium (nutrient poor) containing or not (R)-mellein 350 μg/L ( = 100%) or (-)-terremutin 750 μg/L ( = 100%). Detoxification tests were performed after assessing the toxicity of (R)-mellein and (-)-terremutin on both bacteria and plantlets (see data in Supplementary Figures S1, S2). For both molecules, no toxic effect was observed from 0 to 1500 μg/L neither on the plant nor on the bacterium. Detoxification assays were done in triplicate at 28°C under continuous shaking for 72 h. Percentage of each phytotoxin was determined daily in both bacterial pellet and supernatant (culture medium) obtained after centrifugation. Phytotoxins were extracted from bacterial pellet with acetone (HPLC quality, VWR, France) by shaking for 48 h in darkness at 4°C. Mixture was then centrifuged (5000 g, 15 min, 4°C) and clean supernatant was collected for direct phytotoxin analysis with HPLC as described before. (-)-Terremutin as a highly hydrophilic molecule was directly analyzed in the culture medium by direct injection into HPLC system. However, (R)-mellein was extracted from the culture medium with hexane (10:2 v/v, extraction yield > 90%). After a vigorous shake of 1 min, the upper organic phase was directly used for (R)-mellein analysis with HPLC. Two controls were carried out: living bacteria in a toxin-free medium as a biological control, and medium containing only toxin without living bacteria as a physicochemical control.

Treatment of Grapevine Plantlets With (R)-Mellein and (-)-Terremutin

To investigate phytotoxin’s capacity to modulate plant immunity, 6 weeks old plantlets were treated with bacterial suspension in liquid MS medium at the root level. After 2 weeks, roots of were washed three times in sterile liquid MS, then plantlets were transferred in a new sterile liquid MS medium supplemented or not with (R)-mellein 350 μg/L or (-)-terremutin 750 μg/L for 72 h under growth chamber conditions. Controls consisted of 8 weeks old plantlets on MS medium, further transferred for 3 days on liquid MS medium with or without phytotoxins.

In the meantime, phytotoxins were quantified from plantlet’s incubating medium as described before, and extracted from shoot and roots with methanol (weight/volume: 1/5) in darkness under continuous shaking for 48 h at 4°C. The homogenate was then centrifuged at 5000 g for 15 min at 4°C and the clean supernatant was directly used for phytotoxin analysis by HPLC. All experiments were repeated four times at least in triplicate. Two different controls were carried out: living plants in a toxin-free medium and medium containing only toxin without living plants.

RNA Extraction and qRT-PCR Analysis

Leaf samples from cuttings and shoots from plantlets were collected respectively at 4 days post-inoculation with pathogen and at 3 days post-treatment with phytotoxins, ground in liquid nitrogen then stored at -80°C. Total RNA were extracted from 50 mg of leaf powder for cuttings or from 100 mg of powdered plantlet shoots with PlantRNA Purification Reagent according to manufacturer instructions (Invitrogen, Pontoise, France), and DNase treated as described by Gruau et al. (2015). RNA quality was checked by agarose gel electrophoresis, and total RNA concentration was measured at 260 nm for each sample and adjusted to 100 ng μL-1. First-strand cDNA was synthesized from 150 ng of total RNA using the Verso cDNA synthesis kit (Thermo Fisher Scientific, Inc., Waltham, MA, United States). PCR conditions were those described by Gruau et al. (2015). Quantitative RT-PCR was performed with Absolute Blue qPCR SYBR Green ROX Mix according to manufacturer instructions (Thermo Fisher Scientific, Inc., Waltham, MA, United States), in a BioRad C1000 thermocycler using the BioRad manager software CFX96 Real Time PCR (BioRad, Hercules, CA, United States). A set of 13 defense-related genes, selected for their responsiveness to pathogen or priming state induced by beneficial bacteria (Spagnolo et al., 2012, 2014; Gruau et al., 2015; Magnin-Robert et al., 2016), was tracked by quantitative reverse-transcription-polymerase chain reaction (qRT-PCR) using specific primers (Supplementary Table S1). qRT-PCR reactions were carried out in duplicates in 96-well plates in a 20-μl final volume containing Absolute Blue SYBR Green ROX mix including Taq polymerase ThermoPrime, dNTPs, buffer and MgCl2 (Thermo Fisher Scientific, Inc., Waltham, MA, United States), 280 nM forward and reverse primers, and 10-fold diluted cDNA according to the manufacture’s protocol. Cycling parameters were 15 min of Taq polymerase activation at 95°C, followed by 40 two-step cycles composed of 10 s of denaturation at 95°C and 45 s of annealing and elongation at 60°C. Melting curve assays were performed from 65 to 95°C at 0.5°C⋅s-1, and melting peaks were visualized to check amplification specificity. EF1 and 60SRP genes were used as references and experiments were repeated five times. Relative gene expression was determined with the formula fold induction: 2(-ΔΔCt), where ΔΔCt = [Ct TG (US) – Ct RG (US)] – [Ct TG (RS) – Ct RG (RS)], where Ct is cycle threshold, Ct value is based on the threshold crossing point of individual fluorescence traces of each sample, TG is target gene, RG is reference gene, US is unknown sample, and RS is reference sample. Integration of the formula was performed by the CFX Manager 3.0 software (BioRad). The genes analyzed were considered significantly up- or down-regulated when changes in their expression were > 2-fold or < 0.5-fold, respectively. Control samples for the cuttings model are cDNA from leaves of cuttings untreated with bacteria and inoculated with sterile PDA plugs (1x expression level), while for the in vitro model it corresponds to shoots from plantlets grown on MS medium without PTA-271 and phytotoxins (1x expression level).

Statistical Analysis

To quantify phytotoxins, standard curves were first established with pure phytotoxins through titrations repeated at least three times from two independent experiments. Biocontrol assays with cuttings model were repeated at least three times with at least 10 cuttings per treatment. The confrontation tests between PTA-271 and fungal pathogen were triplicated in experiments conducted twice. Detoxification assays with in vitro PTA-271 or in vitro plantlet model were repeated four times with each sample at least triplicated. Data are means ± standard deviations. Analyses of gene expression by qRT-PCR were repeated five-times from independent experiments. RNAs were extracted from powdered 20 leaves of 10 grapevine cuttings, and from powdered shoots of four plantlets. Results correspond to means ± standard deviation from one representative out of at least three showing the same trends. Statistical analyses were carried out using the SigmaStat 3.5 software. For treatment effect, mean values were compared by Tukey’s test (P < 0.05).

Results

B. subtilis PTA-271 Attenuates Botryosphaeria Dieback Symptoms in Grapevine Cuttings

PTA-271 was used to evaluate its capacity to control the occurrence of Botryosphaeria dieback symptoms. Bioassays with Chardonnay cuttings from control or bacteria-pretreated plants at root level further inoculated with Np-Bt67 showed that PTA-271 significantly reduced the dead branch development (Figure 1A) by approximately 50% compared to non-bacteria pretreated plants (Figure 1E). Similarly, the size of canker (Figure 1B) and those of external and internal stem lesions (Figures 1C,D) were reduced in PTA-271-pretreated cuttings after challenge with Np-Bt67. Both canker and stem lesions were reduced by about 63 to 75% compared to non-bacteria pretreated plants (Figures 1F–H). These results indicate that PTA-271 could efficiently protect Chardonnay cuttings from the N. parvum strain Np-Bt67.

FIGURE 1
www.frontiersin.org

Figure 1. The beneficial bacterium Bacillus subtilis PTA-271 attenuates the characteristic Botryosphaeria dieback symptoms induced in Chardonnay cuttings by the Neofusicoccum parvum strain Np-Bt67. One month pretreated grapevine cuttings with PTA-271 (Bs, 2 × 108 cfu/g soil) and non-bacteria pretreated ones (Ctl) were inoculated with pathogen mycelium (+Np-Bt67). Non-infected plants were inoculated with sterile medium without pathogen (Control). Compared to PTA-271 treated healthy asymptomatic cuttings (A), the infected symptomatic cuttings showed the typical Botryosphaeria dieback symptoms: dead branch (A,E), stem canker (B,F), stem internal necrosis (C,G), and stem external necrosis (D,H) that were photographed (A–D) and quantified (E–H) at 4 months post-inoculation. Data are means ± standard deviation (SD) for at least three independent experiments with 10 biological replicates per treatment. Vertical bars with different letters are significantly different (Multiple Comparison procedures with Tukey’s test, P < 0.05).

B. subtilis PTA-271 Antagonizes N. parvum and Detoxifies Both (R)-Mellein and (-)-Terremutin

In regard to in vitro test with pathogen mycelium, results showed that PTA-271 clearly antagonizes Np-Bt67 by a fungistatic effect compared to control treatment at 28°C (Figure 2A) in both time points. Antifungal effect was detected approximately 4 days after pathogen inoculation at 22°C (Figure 2B). Thereafter, mycelial growth increased progressively and became comparable to the control.

FIGURE 2
www.frontiersin.org

Figure 2. Antagonistic activity of B. subtilis PTA-271 toward the N. parvum strain Np-Bt67. The beneficial bacterium PTA-271 (Bs) and the N. parvum strain Np-Bt67 (Bt67), co-inoculated on the opposite sides of PDA plates, were incubated at 28°C (A) or 22°C (B). Pictures of representative plates among nine were taken from 4 to 13 days depending on mycelial growth. Top photographs are the plates without bacteria (pathogen control) and bottom ones are the plates co-inoculated with pathogen and Bs. Antagonism effect is characterized by an inhibition zone between the bacterial colony (right side) and the fungus (left side).

We also investigated whether PTA-271 can affect fungal toxins, (R)-mellein and (-)-terremutin exogenously applied to their culture medium. Results showed that the percentage of both (R)-mellein and (-)-terremutin was significantly decreased in the presence of PTA-271 (Figure 3). The (R)-mellein decrease was effective after a 48 h latency period in the presence of PTA-271 at 108 cfu/ml, and reached 40% after 72 h of exposure (Figure 3A). Similar effect was observed after 72 h of incubation with PTA-271 at low (104 cfu/ml) or high (2 × 108 cfu/ml) bacterial density (Figure 3B). In addition, the bacterium seems to be effective to remove (R)-mellein, whether suspended in MS medium or in the less nutrient rich MgSO4 medium. The amount of (R)-mellein decreased significantly with the high bacterial density whether in MS medium or in the less nutrient rich MgSO4 medium (Figure 3C). Interestingly, the (-)-terremutin decrease was effective after a 24 h latency period in MS medium in the presence of PTA-271 at 108 cfu/ml to reach 50% after 72 h (Figure 3D). Such a (-)-terremutin decrease was not observed in the presence of the bacterium at lower density (Figure 3E), or in the less nutrient rich MgSO4 medium compared to MS one (Figure 3F).

FIGURE 3
www.frontiersin.org

Figure 3. Detoxifying capacity of B. subtilis PTA-271 (Bs) toward the purified (R)-mellein (A–C) and (-)-terremutin (D–F) from N. parvum. Phytotoxin concentrations were determined as remaining percentages in the bacterial incubating media either: (A,D) daily form MS medium containing PTA-271 (Bs) at 108 cfu/mL, or (B,E) 72 h post-exposure to two distinct bacterial densities 104 and 2 × 108 cfu/mL in MS, or (C,F) 72 h post-exposure to the two distinct incubating media Murashige-Skoog medium (MS) and MgSO4 with Bs at 2.108 cfu/mL. Data are means ± SD of three independent experiments, each with triplicates. The toxin controls (Ctrl) indicated none physicochemical disappearance. Phytotoxins were not detectable inside bacterial pellet. Vertical bars with different letters are significantly different (Multiple Comparison procedures with Tukey’s test, P < 0.05).

B. subtilis PTA-271 Strongly Primes the Expression of a β-1,3-Glucanase After N. parvum Inoculation in Grapevine Cuttings

In leaves of control cuttings inoculated with Np-Bt67, data from qRT-PCR (Figure 4 and Supplementary Figure S3) showed that, except for PR1 (1.4-fold expression), the expression of defense genes responsive to salicylic acid (SA) including PR2, PR5, and PR10 was significantly up-regulated from 6.6- to 7.3-fold. Expression of PAL (phenylalanine ammonia-lyase) and STS (stilbene synthase) involved in the synthesis of phytoalexins was also increased by 1.6- and 3.5-fold, respectively. In the meantime, expression of GST1 encoding a glutathione-S-transferase putatively involved in the detoxification process, and that of PR3 and PR4 as responsive to jasmonic acid/ethylene (JA/ET), was upregulated by 2.7-, 3.3- and 1.3-fold, respectively. Data also showed a low upregulation of the NCED2 gene involved in abscisic acid biosynthesis (1.6-fold), while that of LOX9 was not upregulated by N. parvum.

FIGURE 4
www.frontiersin.org

Figure 4. B. subtilis PTA-271 strongly primes PR2 gene in leaves of grapevine cuttings after infection with the N. parvum strain Np-Bt67. Twelve weeks old plantlets untreated or pretreated with PTA-271 were both infected with sterile PDA plugs (Control and Bs, respectively) or with mycelium plugs of Np-Bt67 (Ctl + Np-Bt67 and Bs + Np-Bt67, respectively). Transcript levels of defense-related genes were monitored by qRT-PCR in leaves at 4 days post infection. Results are from one representative replicate among three independent experiments showing the same trends. Different letters indicate significant differences. PR3 = class IV chitinase (chit4c); PR4 = PR-4 type protein; LOX9 = lipoxygenase 9; PR1 = pathogenesis-related protein 1; PR2 = class I β-1,3-glucanase; PR5 = thaumatin-like protein; GST1 = glutathione-S-transferase 1; PR10 = pathogenesis-related protein 10; PAL = phenylalanine ammonia lyase; STS = stilbene synthase; NCED2 = 9-cis-epoxycarotenoid dioxygenase 2.

The ability of PTA-271 to enhance grapevine immunity was addressed. Gene expression levels after pretreatment with PTA-271 was similar to control plants, before pathogen challenge (Figure 4 and Supplementary Figure S3). However, after Np-Bt67 inoculation, bacteria-pretreated plants showed a significant priming of PR2 (encoding a β-1,3-glucanase), NCED2 and PAL expressions compared to non-bacteria pretreated plants. PR2 mRNA level was more markedly primed in the leaves (23.7-fold). However, only slight differences were observed regarding transcript levels of LOX9, GST1, and STS, while the expression levels of PR1, PR3, PR4, and PR10 did not change in bacteria-treated plants compared to control after pathogen infection.

N. parvum Phytotoxins Repress PTA-271-Mediated SA- and JA-Responsive Gene Expression in Grapevine Plantlets

To focus on the repression of gene expression induced by PTA-271 after toxin application, we first examined how the bacterium affects gene expression in plantlets leaves. Data (Figure 5 and Supplementary Figure S4) showed that PTA-271 alone induced significant changes in the expression of genes responsive to JA/ET (PR3, PR4, LOX9), SA (PR1, PR2, PR5, GST1, PR10) or abscisic acid ABA (NCED2, involved in ABA synthesis) compared to control plantlets. Transcript level was increased from 2.4- to 6.9-fold for JA/ET-responsive genes, from 2.0- to 5.8-fold for SA-responsive ones, and by 4.3 for NCED2. Expression of PAL and STS was also increased by 2.2 and 2.3-fold, respectively, and to a lesser extent for CHI (chalcone isomerase) and NPR1.1 (non-expresser of PR1) reaching 1.3- and 1.9-fold expression, respectively.

FIGURE 5
www.frontiersin.org

Figure 5. (R)-mellein and (-)-terremutin repress the B. subtilis-PTA-271-induced immune responses in grapevine plantlets. Eight weeks old plantlets untreated or pretreated with PTA-271 were further challenged with MS medium (Ctl and Bs, respectively) supplemented with (-)-terremutin (Ctl+T and Bs+T, respectively) or (R)-mellein (Ctl+M and Bs+M, respectively). Transcript levels of defense-related genes were monitored by qRT-PCR in plantlets shoots after 3 days of exposure. Results are from one representative replicate among five independent experiments showing the same trends. A three-color scale was used to show the expression level of each gene. Red shades indicate overexpression and deep red corresponds to an induction factor of 7.94 or more; white represents the basal expression level and signifies that the expression level is not different from the Control; blue shades symbolize repression and dark blue corresponds to a 0.22-fold induction or less. Legends for genes are as in Figure 4. CHI = chalcone isomerase; NPR1.1 = non-expresser of PR genes 1.

After a subsequent exposure to toxins, most of the defense genes induced by PTA-271 were repressed. (-)-Terremutin and (R)-mellein significantly repressed the expression of genes responsive to JA/ET (PR3, PR4, LOX9) and SA (PR2, PR5, PR10), and that of PAL and STS (involved in phenylpropanoid pathway). (R)-mellein additionally repressed the expression GST1, another gene responsive to SA. Expression of the SA-dependent PR1 gene was the sole gene still over induced in PTA-271 treated plantlets after toxin application, as in control plantlets treated with both toxins. Expression of another SA-dependent GST1 gene was the sole gene still over induced in PTA-271 treated plantlets after (-)-terremutin application, as in control plantlets treated with (-)-terremutin. In contrast, expression of the ABA-dependent NCED2 gene was the sole gene still over induced in PTA-271 treated plantlets after each toxin application, while not significantly in control plantlets treated with toxins.

(R)-Mellein and (-)-Terremutin Are Mobilized or Accumulated Differently by PTA-271-Pretreated Plantlets

To investigate the fate of phytotoxins in the incubating medium of plantlets, control and PTA-271-pretreated plants were exposed to (R)-mellein or (-)-terremutin at their root level. As shown in Figure 6A, (R)-mellein quickly decreased in the MS growth medium of control plantlets. The amount of (R)-mellein decreased by about 83.5% within 24 h and by 97.5% after 48 h. In planta (Figure 6B), roots accumulated about 50% of (R)-mellein within 72 h. Experiments with PTA-271-pretreated plantlets showed a partial (R)-mellein removal even after 72 h exposure (Figure 6A), thus confining 20% of (R)-mellein in the incubating medium (Figure 6A), while only 20% of (R)-mellein was accumulated inside the plantlet roots (Figure 6B).

FIGURE 6
www.frontiersin.org

Figure 6. Fate of (R)-mellein and (-)-terremutin from plantlets incubating medium or from medium of B. subtilis-PTA-271-pretreated plantlets. Eight weeks old plantlets treated with PTA-271 were transferred in a new MS medium containing (R)-mellein (Bs + M) 350 μg/L (A,B) or (-)-terremutin (Bs + T) 750 μg/L (C,D). The same experiment was performed with non-bacteria pretreated plantlets, then transferred on (-)-terremutin 750 μg/L (Ctl + T) or (R)-mellein 350 μg/L (Ctl + M). Phytotoxin concentrations were determined either: daily in the plant culture media from 0 to 72 h (A,C), or 72 h post-exposure as percentage accumulated in shoots (S) and roots (R) (B,D). Data are means ± SD of three independent experiments, each with triplicates (at least four plantlets by replicate). The toxin controls indicated none physicochemical disappearance. Phytotoxins were not detectable inside bacterial pellet. Vertical bars with different letters are significantly different (Multiple Comparison procedures with Tukey’s test, P < 0.05).

Supplied (-)-terremutin also decreased significantly from plantlets incubating medium (Figure 6C), especially after a 24 h period of exposure, to reach about 35% from 48 h. At 72 h, no apparent accumulation of (-)-terremutin was noticed in plantlet tissues (Figure 6D). With PTA-271-pretreated plantlets, a similar trend appeared for (-)-terremutin removal from the MS medium (Figure 6C), without any apparent accumulation inside the plant tissues (Figure 6D).

Discussion

The contribution of (R)-mellein and (-)-terremutin to N. parvum aggressiveness was strongly suspected in grapevine, considering their detection in the wood and leaves of Botryosphaeria dieback affected plants (Abou-Mansour et al., 2015) while their secreting pathogens were exclusively wood-confined (Mugnai et al., 1999). However, the role of such phytotoxins in Botryosphaeria infectious process and their potential control by beneficial microbes remain unknown. In this study, we used a N. parvum strain that produces both (R)-mellein and (-)-terremutin, as well as these purified toxins, to understand their role in the N. parvum aggressiveness. We also investigated the capacity of the beneficial bacterium B. subtilis PTA-271 to counteract Botryosphaeria dieback symptoms, and explore whether the bacterium can affect pathogen growth, detoxify pure toxins and prime grapevine immunity after pathogen infection.

Our data provide evidence that N. parvum Np-Bt67 which produces high amount of (-)-terremutin provoked Botryosphaeria dieback symptoms within 10 days on grapevine cuttings, including dead branch, canker and both external and internal stem necrosis (Figure 1). Interestingly, after treatment of cutting at the root level with PTA-271, the Botryosphaeria dieback symptoms were significantly reduced. The PTA-271-pretreated plants showed a reduced dead branch of 50% after Np-Bt67 challenge, accompanied with a strong reduction of canker and stem lesions. This study reports for the first time: (i) the expression of a severe form of Botryosphaeria dieback on Chardonnay plants in controlled conditions, and (ii) that PTA-271 seems to be a very effective bacterium to protect Chardonnay plants against a Botryosphaeria pathogen. This protective effect appears to be related to the ability of the bacterium to antagonize N. parvum by delaying its mycelial growth, to detoxify both (R)-mellein and (-)-terremutin, and to prime few defense genes including PR2 (a β-1,3-glucanase), NCED2 (involved in ABA synthesis) and PAL at systemic level after pathogen inoculation. Indeed PTA-271 was initially isolated from grapevine rhizosphere, while inducing leaf defense responses (Trotel-Aziz et al., 2008). But Santoyo et al. (2016) indicates that all of the genera described as common inhabitants of the rhizosphere, are also bacterial endophytes. Especially Bacillus sp. is the most commonly isolated species from all kinds of grapevine tissues including the wood of both Esca-foliar symptomatic or asymptomatic plants (Bruez et al., 2015). In this study, PTA-271 succeeds to protect grapevine. Whatever the inhabiting zone of PTA-271 or its active molecules, PTA-271 impacts were sought both on mycelium and toxins of fungal pathogen and on plant immunity.

The antagonistic activity of B. subtilis PTA-271 against Np-Bt67 (Figure 2) showed some dependency on temperature, since it is only effective at 28°C. PTA-271 could thus impact the life cycle of N. parvum, especially at 28°C since it clearly appears that PTA-271 grows less at 22°C while using identical bacterial densities at day 0. Thus the less fungal inhibition at 22°C might result from the fact that PTA-271 grows less at 22°C. This fungistatic effect might be explained by the release of various antifungal compounds by PTA-271, including surfactins or other lipopeptides which production was shown to depend on temperature (Ongena and Jacques, 2008; Pinto et al., 2018). Interestingly, PTA-271 can also detoxify the two main phytotoxins of N. parvum to different extents (Figure 3). The detoxifying activity of the bacterium seems to be more active in a nutrient rich medium for (-)-terremutin, but not for (R)-mellein. This suggests that (R)-mellein would be directly metabolized by PTA-271, while (-)-terremutin would require a co-substrate to be co-metabolized by this bacterium. This is consistent with the short latency period needed for (-)-terremutin mobilization from the medium, as already reported for some organic pesticides (Cycon and Piotrowska-Seget, 2016). It has been reported that bacteria can use root exudates such as catechin and coumarin as co-substrates to detoxify recalcitrant organic molecules in situ (Makova et al., 2006). It is thus speculated that grapevine and beneficial bacteria might interact together to improve detoxification process and then ensure an active protection against Botryosphaeria dieback. However, in the case of (R)-mellein, its detoxification rate by bacteria is characterized by a long latency phase followed by a rapid disappearance, even at a low bacterial density (104 cfu/mL). This latency period would be necessary for bacteria to express its detoxifying pathways.

Our results also suggested that PTA-271 might prime the expression of some plant defense genes responsive to different phytohormone pathways (Figure 4). In leaves of control cuttings challenged with Np-Bt67, some genes were slightly up-regulated, especially PR2, PR5, PR10, as SA-responsive genes (Dufour et al., 2013; Naznin et al., 2014; Caarls et al., 2015), while the expression of PR4, LOX9, as JA/ET responsive genes (Hamiduzzaman et al., 2005; Naznin et al., 2014) remained low. This suggests that the early activation of SA-signaling during pathogen’s biotrophic phase could antagonize the expression of JA-dependent-defenses useful for grapevine once pathogen entered its necrotrophic phase as indicated by Yang et al. (2015). This could result from the pathogen strategy to overcome host defenses and thus promote disease. In the same sense, a late and weak defense’s expression has been already observed in grapevines developing Botryosphaeria dieback symptoms in vineyards (Spagnolo et al., 2014). In PTA-271-pretreated plants, PR2 was highly primed after pathogen inoculation, and to a weakest extent for LOX9 as JA-dependent, GST1, PAL, and STS associated to secondary metabolism, or NCED2 involved in ABA biosynthesis. Interestingly, the expression of PR2 gene is described to be regulated by various phytohormones such as SA, JA, and ET (Liu et al., 2010). Up to date, it is still unclear how the SA-induced cellular changes can influence JA-inducible responses (Caarls et al., 2015). Pretreatment with PTA-271 might thus up-regulate PR2 expression in a JA-dependent way. PR2 encodes a β-1,3-glucanase, which could play an important role in grapevine defense, either directly, through the degradation of pathogen cell wall, or indirectly, by releasing oligosaccharide elicitors that could induce additional plant defenses (Renault et al., 2000). Although this priming effect essentially but indisputably concerns more PR2 following Np-Bt67 challenge, it does not counter balance the PTA-271 priming capacity toward grapevine pathogens. Indeed, primed plants usually show no enhanced expression of phenotypic defense traits, but they respond faster or more strongly following the pathogen challenge inoculation (Conrath et al., 2006; Goellner and Conrath, 2008), as observed for PR2 with PTA-271 treated cuttings at this time point of analysis (4 dpi). Verhagen et al. (2011) also showed a PTA-271 capacity to induce slight plant leaf defense responses, but further potentiated upon B. cinerea challenge (from 3 to 7 dpi, using a plantlet model). We also showed (Trotel-Aziz et al., 2008) that PTA-271 can stimulate JA/ET-dependent defenses in grapevine against the necrotrophic fungus B. cinerea. Regarding the expression of NCED2 primed by PTA-271 upon pathogen challenge, our data cannot exclude a possible contribution of ABA biosynthesis to an enhanced JA biosynthesis (Adie et al., 2007) that remains to be further elucidated.

Deciphering now grapevine immune response using plantlets directly exposed to (R)-mellein and (-)-terremutin (Figure 5), our data showed that application of (R)-mellein and (-)-terremutin resulted in up-regulation of the SA-responsive genes PR1 and GST1, respectively (Devadas et al., 2002). GST1 is also part of the array of defense-related genes induced in response to oxidative burst produced after pathogen infection (Bhattacharjee, 2012). Contrary to SA-responsive genes, the expression of JA/ET-responsive genes remained weak as shown previously during grapevine-Np-Bt67 interaction, or even down-regulated by (-)-terremutin (i.e., PR3). This can be supported by the fact that (-)-terremutin is a derivative of 6-methyl-SA (Guo et al., 2014) as a mobile signal easily hydrolysable to active SA (Park et al., 2007; Kumar and Klessig, 2008). It is thus tempting to correlate (-)-terremutin to the necrotrophic stage of Np-Bt67 lifestyle, and to speculate the mimicking of SA effect to antagonize JA-dependent defenses. In contrast, (R)-mellein induced both the SA-responsive PR1 and PR5 and to a weaker extent the JA/ET-dependent PR4 gene. Thus, (R)-mellein produced by N. parvum might be mainly in link with the biotrophic and early necrotrophic stages of pathogen with hemibiotrophic lifestyle (Duan et al., 2014; Ross et al., 2014; Yang et al., 2015). In PTA-271 pretreated plantlets (Figure 5), both JA/ET- and SA-responsive genes were up-regulated, as well as an ABA biosynthetic gene (NCED2) and phenylpropanoid pathway genes (PAL, STS) in in vitro-plantlets. These data are in agreement with those of Trotel-Aziz et al. (2008) using the same plantlet model. However, exogenous application of (-)-terremutin and (R)-mellein repressed the expression of almost all of the PTA-271 up-regulated host-defense-genes. The enhanced expression of GST1 by PTA-271 was weakly repressed by (-)-terremutin, suggesting that GST could take part to the detoxification process of (-)-terremutin or maybe in the redox regulation in SA/JA crosstalk. Some authors have indicated that overexpression of GST1 might mediate redox changes to prevent some pathogen aggressive molecules to mimic SA-signaling to overcoming host immunity (Tada et al., 2008; Vidhyasekaran, 2015). Interestingly, up-regulation of NCED2 by PTA-271 was not altered by fungal toxins, emphasizing the role of ABA as a central component to overcome toxin effects by a possible enhancement of JA synthesis (Adie et al., 2007; Mohr and Cahill, 2007; Spoel and Dong, 2008). Many studies reported that endogenously accumulated SA antagonizes JA-dependent defenses, thereby prioritizing SA-dependent resistance over JA-dependent defense (Pieterse et al., 2012; Van der Does et al., 2013). Indeed PR1 was the sole gene still over-induced in PTA-271 pretreated plantlets exposed to each pure toxin. This is consistent with our hypothesis of a SA mimicking effect to antagonize the host JA-dependent defenses. Deciphering the extend of cross-communication in the hormone signaling pathways, through fine tuning of transcriptional programs, would thus enable to better understand the mechanisms contributing to grapevine basal and induced resistances to GTD pathogens. The potential roles of GST1 overexpressed in the presence of (-)-terremutin, and of NCED2 upregulated in the presence of PTA-271, would now merit a greater attention.

PTA-271 beneficial effect might also target grapevine detoxifying capacity on GTD-secreted phytotoxins. Control plantlets can mobilize both (R)-mellein and (-)-terremutin when exogenously applied at the root level (Figure 6). (R)-Mellein is entirely mobilized and may be accumulated in planta in its native chemical form, while (-)-terremutin was partly mobilized and was not accumulated in planta. In contrast, in PTA-271-pretreated plantlets, only (R)-mellein mobilization was slightly reduced. Treatment with PTA-271 might thus slow down the (R)-mellein uptake by grapevine plantlets. The distinct chemical structures of each toxin still remain to be investigated (i.e., toxin conjugates), as well as the mechanisms slowing down (R)-mellein entry in plantlets, to better understand how PTA-271 might exert its beneficial effects on grapevine’s detoxifying capacity.

Conclusion

Altogether, our results provide evidences that (-)-terremutin and (R)-mellein are usefull molecules for N. parvum that can secrete them inside the host to fully express its virulent character. Once inside the plant (-)-terremutin and (R)-mellein may reprogram grapevine immunity enabling the pathogen to overcome host defenses and thus promote disease. However, the beneficial bacterium PTA-271 significantly attenuated the Botryosphaeria dieback symptoms, by antagonizing N. parvum growth, inducing plant systemic resistance as shown by the strong PR2 priming among the few host defense responses in the tested time point, and detoxifying both (R)-mellein and (-)-terremutin produced by Np-Bt67.

Author Contributions

PTA planned and designed the research, performed most of the experiments, analyzed the data, and wrote the manuscript with the contributions and discussion from AA, FF, EAM, and CC. FF, AA, EAM, and CC validated the planned research and gave their expertise for all steps of this work. EAM prepared all purified toxins for the experiments. BC performed most of the qRT-PCR experiments and prepared grapevine plantlets. FR ensured the quality of qRT-PCR analysis and data.

Funding

The work included in the CASDAR V1301 project was funded by the French Agriculture Ministry and the Interprofessional Comity of Vine in France (CNIV).

Conflict of Interest Statement

The authors declare that the research was conducted in the absence of any commercial or financial relationships that could be construed as a potential conflict of interest.

Acknowledgments

We are grateful to Dr. Cecilia Rego (Higher Institute of Agronomy, Lisbon University, Portugal) for pathogen gift. Thanks are also due to Isabelle Roberrini for her technical assistance.

Supplementary Material

The Supplementary Material for this article can be found online at: https://www.frontiersin.org/articles/10.3389/fpls.2019.00025/full#supplementary-material

FIGURE S1 | Toxicity assessment of (R)-mellein and (-)-terremutin toward B. subtilis PTA-271 (Bs) in 24 h. PTA-271 was sprayed on PDA plates containing one central phytotoxin drop (5 μL) from 0 to 60 mg/L for (R)-mellein (M0 to M60) or (-)-terremutin (T0 to T60).

FIGURE S2 | Toxicity assessment of (R)-mellein and (-)-terremutin towardin vitro-plantlets. Eight weeks old plantlets were exposed to MS medium containing (R)-mellein or (-)-terremutin at concentrations ranging from 0 to 1500 μg/L. Three days post-exposure (dpe) to phytotoxin, toxicity was assessed through maximum quantum yield of photosynthesis (Fv/Fm), fresh weight and pigment concentrations. The maximum photosynthetic capacity of the plants was obtained by measuring the Fv/Fm parameter given by a PAM-Pulse Amplitude Modulated fluorimeter equipped with the Modfluor v2.00 software (Hansath, London, United Kingdom) according to the recommendations of Genty et al. (1990). The content of chlorophylls a, b, and carotenoids was obtained by colorimetric assay (spectrophotometry at 470, 652.4, and 665.2 nm) after pigments extraction in pure methanol (20 min at 65°C) and quantified according to Wellburn (1994) formulas. Data are means ± SD of three independent experiments, each with four replicates. None bars were headed with asterisks, indicating none significant differences (Multiple Comparison procedures with Tukey’s test, P < 0.05).

FIGURE S3 |B. subtilis PTA-271 primes some defense-related genes in leaves of grapevine cuttings after infection with the N. parvum strain Np-Bt67. Legend as in Figure 4. Three-color scale as in Figure 5, with deep red corresponding to an induction factor of 23.71 or more, and dark blue corresponding to a 0.55-fold induction or less.

FIGURE S4 | (R)-Mellein and (-)-terremutin repress the B. subtilis-PTA-271-induced immune responses in grapevine plantlets. Different letters indicate significant differences. Legend as in Figure 5.

TABLE S1 | Primer sequences used for qRT-PCR analysis of defense-related genes.
