Abstract
Naturally colored cotton (NCC) offers an environmentally friendly fiber for textile applications. Processing white cotton fiber into textiles requires extensive energy, water, and chemicals, whereas processing of NCC skips the most polluting activity, scouring-bleaching and dyeing; therefore, NCC provides an avenue to minimize the harmful impacts of textile production. NCC varieties are suitable for organic agriculture since they are naturally insect and disease-resistant, salt and drought-tolerant. Various fiber shades, ranging from light green to tan and brown, are available in the cultivated NCC (Gossypium hirsutum L.) species. The pigments responsible for the color of brown cotton fiber are proanthocyanidins or their derivatives synthesized by the flavonoid pathway. Due to pigments, the NCC has excellent ultraviolet protection properties. Some brown cotton varieties exhibited superior thermal resistance of fiber that can be used to make fabrics with enhanced flame retardancy. Here, we review molecular mechanisms involved in the pigment production of brown cotton and challenges in breeding NCC varieties with a wide range of colors but without penalty in fiber quality. Also, we discuss opportunities for NCC with flame-retarding properties in textile applications.
Introduction
Naturally colored cotton (NCC) fibers exist in different hues of brown, red, rust, and green and can be used as eco-friendly alternatives to white cotton (Figure 1). The conventional process of dyeing white cotton requires extensive water, energy, and chemicals and contributes about 15% to the cost of the finished garment (). NCC fabrics resist fading since colors become stronger after laundering (). Due to pigments, the clothes made from NCC fibers protect the skin from ultraviolet radiation. Fibers of some brown cotton varieties exhibited flame retardant (FR) properties, making them suitable for specific end-use applications, such as automotive interiors (; , ; , ).
Figure 1
Despite these advantages, typical NCC fibers are weaker and shorter than cultivated white cotton fibers, deeming them unsuitable for high-speed woven textile machinery. The breeding efforts in the 1990s resulted in the release of improved brown fiber germplasm lines (). However, the major obstacle to expanding NCC production is not marketing but regulations to protect white cotton from contamination during ginning and the cost associated with cleaning equipment (). Limited color diversity is another hindrance to expanding the NCC to commercial textile production (; ). Currently, NCC occupies a textile market niche promoting environmentally friendly clothing production.
Nevertheless, the use of NCC has great merit and should be expanded since global textile production generates toxic chemical waste with a negative impact on the environment. A recent forum article reviewed molecular mechanisms underlying pigmentation in brown and green cotton and suggested “omics-driven breeding” for better fiber quality NCC (). Here, we review the regulation of pigment development in brown cotton and possible biotechnological strategies to increase hue diversity and improve fiber yield and quality. Also, we discuss the source of FR in brown cotton.
Pigments in brown cotton fibers
Brown cotton varieties are most commonly used for NCC fabrics. Proanthocyanidins (PAs) are the primary pigments responsible for brown fibers. PAs, also called condensed tannins, are polymeric flavan-3-ols with the diphenylpropane typical chemical structure (C6-C3-C6), which includes a benzopyran (A and C rings) linked with another aromatic ring (B ring) at C2 position (Figure 2) (). The adjacent subunits of PA are linked by C4-C8 or C4-C6 carbon-carbon bonds (). PAs were initially detected in brown fibers with DMACA (p-Dimethylaminocinnamaldehyde) staining. A comparative study of the treatment of mature white, green, and brown fibers with DMACA determined that only brown fibers turned blue, while white and green fibers did not change color (). However, PAs in minimal quantities were detected in developing white fibers from 5 to 15 days post-anthesis (DPA) and, after that, gradually disappeared (). In contrast, PAs were detected as early as 3 DPA in developing brown fibers and were synthesized in high quantities up to maturation ().
Figure 2
The common flavan-3-ols are (+)-catechin (2,3-trans) and (-)-epicatechin (2,3-cis) with the gallate modification of the hydroxyl group at the C3’ position on the B-ring (Figure 2) (
PA biosynthesis in brown cotton
PAs are synthesized through the flavonoid pathway, a branch of the phenylpropanoid pathway (
Transcriptomic and proteomic studies in cotton identified that a set of structural genes of the flavonoid pathway, including PAL, C4H, 4CL, CHS, CHI, F3H, F3’H, DFR, LAR, ANS, ANR, were up-regulated in brown fibers (
Three classes of proteins, including TT2 (MYB123), TT8 (bHLH42), and TTG1 (WD40 family), often referred to as MBW complex, are primary regulators of PA biosynthesis. Experimental studies showed that TT2 and TT8 activate PA pathway genes while TTG1 stabilizes the MBW complex and is essential in maintaining MBW activity genes (
Progress on research to enhance color diversity in NCC
The first report that inadvertently shifted the carbon flow from colorless PAs into colorful anthocyanidins in brown fibers was trying to suppress GhCHI-1 (
Another study has exploited color diversity in NCC by modulating the expression of transcription factors controlling anthocyanin biosynthesis genes. The transcription factor GhMYB113 (Re), which regulates anthocyanin biosynthesis, has been overexpressed in cotton under fiber-specific promoter (
How do we prevent the conversion of anthocyanins into PAs during the late stage of fiber development? One possible approach is activating anthocyanin biosynthesis during the later stage of fiber development, and a recent study demonstrated that it is feasible. The GhTT2-3A (Gh_A07G2341) was overexpressed under the secondary cell wall (SCW) specific promoter (FbL2A) in cotton; PA structural genes and PA biosynthesis were activated during the SCW stage in transgenic plants that resulted in brown mature fiber with lint percentage and fiber quality comparable to white fiber control (
Enhanced flame retardancy of NCC
What is causing the flame retardancy (FR) of NCC still remains unclear. Few studies have been published on NCC fabrics’ thermal and burning behavior. The earlier work detected a higher value of limited oxygen index for brown than for white cotton fabric (
More recent studies suggested that PA biosynthesis plays a vital role in the natural FR of brown cotton (Figure 2).
Utilization of NCC
NCC has been cultivated and used for thousands of years; however, with the Industrial Revolution and the development of synthetic dyes, NCC varieties became less common as white cotton became the standard. Recently, interest in NCC has resurged due to its sustainability and environmental benefits since NCC cultivation is adaptable to dry land and organic farming (
NCC is primarily used in high-end fashion, home textiles, upholstery fabrics, etc (
Some NCC varieties possess flame-retardant properties which can be used in various applications. For example, flame-retardant textiles can be used as protective clothing for firefighters, gear for soldiers, automobile interiors, matrasses, house upholsteries, and drapes. Currently, cotton-based textiles are chemically modified to introduce multifunctional groups, making them flame-retardant. The most common method is to merge N, S, P, and Si-based polymeric, non-polymeric, polymeric/non-polymeric hybrids, inorganic, and organic/inorganic hybrids with cellulose to fabricate flame-retardant cotton textiles (
Concluding remarks
The biosynthesis of PAs in brown cotton has been well characterized through transgenic analysis of structural flavonoid genes. However, little is known about how PA units are modified and transported into the vacuole and how PAs are polymerized. It has been experimentally demonstrated that the SCW biosynthesis stage of fiber development is the most suitable time for biotechnological modification of the flavonoid pathway. The anthocyanin pathway can be induced in cotton fibers by overexpressing Re (GhMYB113). In future studies, it would be interesting to overexpress Re and anthocyanidin modifiers during the SCW stage of fiber development to see the effects on the color of fibers. The FR has been detected in brown and white cotton fibers. The FR compound, which is yet to be identified, could be an eco-friendly alternative to synthetic FR additives in textiles. The utilization of NCC remains a niche in the textile industry. However, usage of NCC will likely continue to increase as consumer demand for sustainable and environmentally friendly products grows.
Statements
Author contributions
MN: Writing – original draft; Writing – review & editing. DH: Writing – review & editing. GT: Writing – review & editing.
Funding
The author(s) declare that financial support was received for the research, authorship, and/or publication of this article. The United States Department of Agriculture, Agricultural Research Service financially supported the research (CRIS project 6054-21000-019-00D). The mention of trade names or commercial products is solely for the purpose of providing specific information and does not imply recommendation or endorsement by USDA. USDA is an equal opportunity provider and employer.
Conflict of interest
The authors declare that the research was conducted in the absence of any commercial or financial relationships that could be construed as a potential conflict of interest.
Publisher’s note
All claims expressed in this article are solely those of the authors and do not necessarily represent those of their affiliated organizations, or those of the publisher, the editors and the reviewers. Any product that may be evaluated in this article, or claim that may be made by its manufacturer, is not guaranteed or endorsed by the publisher.
References
1
BaudryA.HeimM. A.DubreucqB.CabocheM.WeisshaarB.LepiniecL. (2004). TT2, TT8, and TTG1 synergistically specify the expression of BANYULS and proanthocyanidin biosynthesis in Arabidopsis thaliana. Plant J.39, 366–380. doi: 10.1111/j.1365-313X.2004.02138.x
2
CanavarÖ.RausherM. D. (2021). Molecular analysis of structural genes involved in flavonoids biosynthesis in naturally colored cotton. Crop Sci.61, 1117–1126. doi: 10.1002/csc2.20410
3
DixonR. A.SarnalaS. (2020). Proanthocyanidin biosynthesis-a matter of protection. Plant Physiol.184, 579–591. doi: 10.1104/pp.20.00973
4
DixonR. A.XieD.-Y.SharmaS. B. (2005). Proanthocyanidins: A final frontier in flavonoid research? New Phytol.165, 9–28. doi: 10.1111/j.1469-8137.2004.012
5
DuttY.WangX. D.ZhuY. G.LiY. Y. (2004). Breeding for high yield and fiber quality in colored cotton. Plant Breed.123, 145–151. doi: 10.1046/j.1439-0523.2003.00938.x
6
FengH.LiY.WangS.ZhangL.LiuY.XueF.et al. (2014). Molecular analysis of proanthocyanidins related to pigmentation in brown cotton fiber (Gossypium hirsutum L.). J. Exp. Bot.65, 5759–5769. doi: 10.1093/jxb/eru286
7
FunkP.GambleG. R. (2009). Fiber properties of saw and roller ginned naturally colored cottons. J. Cotton. Sci.13, 166–173.
8
GaoJ.ShenL.YuanJ.ZhengH.SuQ.YangW.et al. (2019). Functional analysis of GhCHS, GhANR and GhLAR in colored fiber formation of Gossypium hirsutum L. BMC Plant Biol.19, 1–18. doi: 10.1186/s12870-019-2065-7
9
GünaydinG. K.AvincO.PalamutcuS.YavasA.SoydanA. S. (2019). “Naturally colored organic Cotton and Naturally Colored Cotton Fiber Production,” in Organic Cotton: Is it a Sustainable Solution? Eds. GardettiM. A.MuthuS. S. (Springer Singapore, Singapore), 81–99.
10
HinchliffeD.CondonB.DelhomC. D.ChangS.MontalvoJ.MadisonC.et al. (2015). Physical and combustion properties of nonwoven fabrics produced from conventional and naturally colored cottons. Textile. Res. J.85, 1666–1680. doi: 10.1177/0040517515573410
11
HinchliffeD. J.CondonB. D.ThyssenG.NaoumkinaM.MadisonC. A.ReynoldsM.et al. (2016). The GhTT2_A07 gene is linked to the brown color and natural flame retardancy phenotypes of Lc1 cotton (Gossypium hirsutum L.) fibers. J. Exp. Bot.67, 5461–5471. doi: 10.1093/jxb/erw312
12
IslamM. S.van de VenT. G. M. (2021). Cotton-based flame-retardant textiles: A review. BioResources16, 4354–4381.
13
KohelR. J. (1985). Genetic analysis of fiber color variants in cotton1. Crop Sci.25, cropsci1985.0011183X0025000500017x. doi: 10.2135/cropsci1985.0011183X0025000500017x
14
LiT.FanH.LiZ.WeiJ.LinY.CaiY. (2012). The accumulation of pigment in fiber related to proanthocyanidins synthesis for brown cotton. Acta Physiol. Plant.34, 813–818. doi: 10.1007/s11738-011-0858-x
15
LiY.-J.ZhangX.-Y.WangF.-X.YangC.-L.LiuF.XiaG.-X.et al. (2013). A comparative proteomic analysis provides insights into pigment biosynthesis in brown color fiber. J. Proteomics78, 374–388. doi: 10.1016/j.jprot.2012.10.005
16
LiuH.-F.LuoC.SongW.ShenH.LiG.HeZ.-G.et al. (2018). Flavonoid biosynthesis controls fiber color in naturally colored cotton. PeerJ6, e4537. doi: 10.7717/peerj.4537
17
LuN.RoldanM.DixonR. A. (2017). Characterization of two TT2-type MYB transcription factors regulating proanthocyanidin biosynthesis in tetraploid cotton, Gossypium hirsutum. Planta246, 323–335. doi: 10.1007/s00425-017-2682-z
18
MayO. L.GreenC. C.RoachS. H.KittrellB. U. (1994). Registration of PD 93001, PD 93002, PD 93003, and PD 93004 germplasm lines of upland cotton with brown lint and high fiber quality. Crop Sci.34, 542–542.
19
NamS.CondonB. D.XiaZ.NagarajanR.HinchliffeD. J.MadisonC. A. (2017). Intumescent flame-retardant cotton produced by tannic acid and sodium hydroxide. J. Analytical. Appl. Pyrolysis.126, 239–246. doi: 10.1016/j.jaap.2017.06.003
20
NamS.KimH. J.CondonB. D.HinchliffeD. J.ChangS.McCartyJ. C.et al. (2016). High resistance to thermal decomposition in brown cotton is linked to tannins and sodium content. Cellulose23, 1137–1152. doi: 10.1007/s10570-016-0871-8
21
NimonW.BeghinJ. (1999). Are eco-labels valuable? Evidence from the apparel industry. Am. J. Agric. Econ.81, 801–811. doi: 10.2307/1244325
22
ParmarM. S.ChakrabortyM. (2001). Thermal and burning behavior of naturally colored cotton. Textile. Res. J.71, 1099–1102. doi: 10.1177/004051750107101211
23
PengZ.GaoQ.LuoC.GongW.TangS.ZhangX.et al. (2020). Flavonoid biosynthetic and starch and sucrose metabolic pathways are involved in the pigmentation of naturally brown-colored cotton fibers. Ind. Crops Products.158, 113045. doi: 10.1016/j.indcrop.2020.113045
24
RathinamoorthyR.ParthibanM. (2019). “Colored Cotton: Novel Eco-friendly Textile Material for the Future,” in Handbook of Ecomaterials. Eds. MartínezL. M. T.KharissovaO. V.KharisovB. I. (Springer International Publishing, Cham), 1499–1519.
25
SunJ.SunY.ZhuQ.-H. (2021). Breeding next-generation naturally colored cotton. Trends Plant Sci.26, 539–542. doi: 10.1016/j.tplants.2021.03.007
26
TanJ.TuL.DengF.HuH.NieY.ZhangX. (2013). A genetic and metabolic analysis revealed that cotton fiber cell development was retarded by flavonoid naringenin. Plant Physiol.162, 86–95. doi: 10.1104/pp.112.212142
27
ThyssenG. N.CondonB. D.HinchliffeD. J.ZengL.NaoumkinaM.JenkinsJ. N.et al. (2023). Flame resistant cotton lines generated by synergistic epistasis in a MAGIC population. PloS One18, e0278696. doi: 10.1371/journal.pone.0278696
28
WangN.ZhangB.YaoT.ShenC.WenT.ZhangR.et al. (2022). Re enhances anthocyanin and proanthocyanidin accumulation to produce red foliated cotton and brown fiber. Plant Physiol.189, 1466–1481. doi: 10.1093/plphys/kiac118
29
WenT.WuM.ShenC.GaoB.ZhuD.ZhangX.et al. (2018). Linkage and association mapping reveals the genetic basis of brown fiber (Gossypium hirsutum). Plant Biotechnol. J.16, 1654–1666. doi: 10.1111/pbi.12902
30
XiaoY.-H.YanQ.DingH.LuoM.HouL.ZhangM.et al. (2014). Transcriptome and biochemical analyses revealed a detailed proanthocyanidin biosynthesis pathway in brown cotton fiber. PloS One9, e86344. doi: 10.1371/journal.pone.0086344
31
XiaoY.-H.ZhangZ.-S.YinM.-H.LuoM.LiX.-B.HouL.et al. (2007). Cotton flavonoid structural genes related to the pigmentation in brown fibers. Biochem. Biophys. Res. Commun.358, 73–78. doi: 10.1016/j.bbrc.2007.04.084
32
XieD.-Y.DixonR. A. (2005). Proanthocyanidin biosynthesis – still more questions than answers? Phytochemistry66, 2127–2144. doi: 10.1016/j.phytochem.2005.01.008
33
XieD. Y.SharmaS. B.DixonR. A. (2004). Anthocyanidin reductases from Medicago truncatula and Arabidopsis thaliana. Arch. Biochem. Biophys.422, 91–102. doi: 10.1016/j.abb.2003.12.011
34
XieD.-Y.SharmaS. B.PaivaN. L.FerreiraD.DixonR. A. (2003). Role of anthocyanidin reductase, encoded by BANYULS in plant flavonoid biosynthesis. Science299, 396–399. doi: 10.1126/science.1078540
35
YanQ.WangY.LiQ.ZhangZ.DingH.ZhangY.et al. (2018). Up-regulation of Gh TT 2-3A in cotton fibers during secondary wall thickening results in brown fibers with improved quality. Plant Biotechnol. J.16, 1735–1747. doi: 10.1111/pbi.12910
36
YangM.YangY.ShiJ.RaoW. (2023). Fabrication of eco-friendly flame-retardant and hydrophobic coating for cotton fabric. Cellulose30, 3267–3280. doi: 10.1007/s10570-023-05051-9
37
YuK.SongY.LinJ.DixonR. A. (2023). The complexities of proanthocyanidin biosynthesis and its regulation in plants. Plant Commun.4, 100498. doi: 10.1016/j.xplc.2022.100498
38
YuanS. N.MalikW.BibiN.WenG. J.NiM.WangX. D. (2013). Modulation of morphological and biochemical traits using heterosis breeding in colored cotton. J. Agric. Sci.151, 57–71. doi: 10.1017/S0021859612000172
39
ZhuY.WangH.PengQ.TangY.XiaG.WuJ.et al. (2015). Functional characterization of an anthocyanidin reductase gene from the fibers of upland cotton (Gossypium hirsutum). Planta241, 1075–1089. doi: 10.1007/s00425-014-2238-4
